Panduit DP6 24-Port Cat6a 10Gig Punchdown Patch Panel 1RUDescription:
Panduit DP6 24-Port Cat6 10-Gig Patch PanelFeatures:
Exceed requirements of ANSI/TIA/EIA-568-B.2-10 Category 6A, IEEE 802.3an-2006, and ISO 11801 Class EA channel standards
Exceed requirements of ANSI/TIA/EIA-568-B.2-10 Category 6A and IEC 61156-5 Category 6A component standards
Meet draft requirements of IEEE 802.3at for PoE Plus
Each port is 100% tested to ensure NEXT and RL performance and is individually serialized to support traceability
Utilize 110 punchdown termination on back panel and include retention cap for each port
Each port contains a universal label that is color-coded for T568A and T568B wiring schemes
Contacts plated with 50 microinches of gold for superior performance
Angled versions allow for higher density applications by easily routing the patch cords to each side of the panel eliminating the need for horizontal cable management
Terminate 4-pair, 22 - 26 AWG, 100 ohm, solid or stranded twisted pair cable
Mount to standard EIA 19" rack or 23" racks with optional extender bracket
Write-on areas for port and panel identification
Can be clearly identified with labels and icons
Optional label kits (DPLK24 and DPLK48) contain adhesive label holder and labels for easy port and panel identification
