Learn more about PLANET & StandardsFormatDIN-rail and Wall-mount EarStandardsIEEE 802.3 10BASE-TIEEE 802.3u 100BASE-TXIEEE 802.3ab Gigabit 1000BASE-TIEEE 802.3x Flow Control and Back PressureIEEE 802.3ad Port Trunk with LACPIEEE 802.1D Spanning Tree ProtocolIEEE 802.1w Rapid Spanning Tree ProtocolIEEE 802.1s Multiple Spanning Tree ProtocolIEEE 802.1p Class of ServiceIEEE 802.1Q VLAN TaggingIEEE 802.1x Port Authentication Network ControlIEEE 802.1ab LLDPRFC 768 UDPRFC 793 TFTPRFC 791 IPRFC 792 ICMPRFC 2068 HTTPRFC 1112 IGMP v1RFC 2236 IGMP v2RFC 3376 IGMP v3RFC 2710 MLD v1RFC 3810 MLD v2Network Management TypeManagedPorts & InterfacePrimary Ports8 x RJ45Primary Port Speed10/100/1000MbpsData TransmissionMAC Address Table8KSwitching MethodStore and ForwardVLAN Support802.1Q tagged-based VLANUp to 256 VLAN groups, out of 4094 VLAN IDs802.1ad Q-in-Q tunneling (VLAN stacking)Voice VLANProtocol VLANPrivate VLAN (Protected port)GVRPManagement VLANJumbo Frames10KBDetailsBuffer Memory4.1MBProtocolsSpanning Tree Protocol:IEEE 802.1D Spanning Tree Protocol (STP)IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)STP BPDU Guard, BPDU Filtering and BPDU ForwardinSecurityStorm Control support:Broadcast/unknown unicast/unknown multicastAuthentication:IEEE 802.1X port-based network access authenticationBuilt-in RADIUS client to cooperate with the RADIUS serversDHCP Option 82RADIUS/TACACS+ authenticationAccess Control List:IPv4/IPv6 IP-based ACLIPv4/IPv6 IP-based ACEMAC-based ACLMAC-based ACEMAC Security:Static MACMAC filteringPort security for source MAC address entries filteringDHCP snooping to filter distrusted DHCP messagesDynamic ARP inspection discards ARP packets with invalid MAC address to IP address bindingIP source guard prevents IP spoofing attacksDoS attack preventionPoEPoE Standard: IEEE 802.3af/802.3at Power over Ethernet PSEPoE Power Supply Type: End-spanPoE Power Output:IEEE 802.3af StandardPer port 48V - 56V DC (depending on the power supply), max. 15.4 wattsIEEE 802.3at StandardPer port 50V - 56V DC (depending on the power supply), max. 36 wattsPower Pin Assignment: 1/2 (+), 3/6 (-)PoE Power Budget: 144 watts (depending on power input)Max. Number of Class 2 PD: 4Max. Number of Class 3 PD: 4Max. Number of Class 4 PD: 4SNMPYesQoS8 mapping IDs to 8 level priority queuesPort number802.1p priorityDSCP/IP precedence of IPv4/IPv6 packetsTraffic classification based, strict priority and WRRIngress/Egress Rate Limit per port bandwidth controlLACPYesLayer2Port MirroringMany-to-1 monitorLEDs3 x LED for System and Power:Green: DC Power 1Green: DC Power 2Green: Power Fault2 x LED for PoE Copper Port (Port-1~Port-4):Green: LNK/ACTOrange: PoE-in-use2 x LED for 10/100/1000T Copper Port (Port-5~Port-8):Green: LNK/ACTOrange: 1000Mbps4 x LED for PoE Power Usage (W):Orange: 30, 60, 90 and 120WButtonReset Button:< 5 sec: System reboot> 5 sec: Factory defaultPower48 - 56V DC, 3.5A (max.)5.04 watts, 17.1BTU (Standby without PoE function)7.28 watts, 23 BTU (Full loading without PoE function)151.28 watts, 516.1 BTU (Full loading with PoE function)FeaturesFeaturesPhysical Port:8-port 10/100/1000BASE-T Gigabit RJ45 copper with 4-port IEEE 802.3at/af PoE Injector (Port-1 to Port-4)RJ45 console interface for switch basic management and setupIndustrial Case & Installation:IP30 aluminum caseDIN-rail and wall-mounted designSupports -40 to 75 degrees C operating temperatureSupports ESD 6KV DC Ethernet protectionRedundant power design: 48V - 56V DC wide power inputSwitching:Hardware based 10/100Mbps (half/full duplex), 1000Mbps (full duplex), auto-negotiation and auto MDI/MDI-XFeatures Store-and-Forward mode with wire-speed filtering and forwarding ratesIEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation8K MAC address table size10K jumbo frameAutomatic address learning and address agingSupports CSMA/CD protocolLayer 2 Features:Supports VLANSupports Spanning Tree ProtocolSupports Link AggregationProvides port mirror (many-to-1)Loop protection to avoid broadcast loopsMulticast:Supports IPv4 IGMP snooping v2, v3Supports IPv6 MLD snooping v1, v2IGMP querier mode supportIGMP snooping port filteringMLD snooping port filteringManagement:IPv4 and IPv6 dual stack managementSwitch Management InterfaceUser privilege levels controlBuilt-in Trivial File Transfer Protocol (TFTP) clientStatic and DHCP for IP address assignmentSystem MaintenanceSNTP Network Time ProtocolCable diagnosticsLink Layer Discovery Protocol (LLDP) Protocol and LLDP-MEDSNMP trap for interface Link Up and Link Down notificationEvent message logging to remote syslog serverFour RMON groups (history, statistics, alarms and events)PLANET Smart Discovery UtilityDimensions & WeightDimensions2.83" x 6.34" x 4.21"Weight2.21 lbs.EnvironmentalTemperature-40 - 75 degree Celsius (Operating)-40 - 85 degree Celsius (Storage)Humidity5% - 95%, Non-condensingShippingEnjoy fast and reliable shipping when you buy your products from Newegg. Our ordering and shipping services are among the best in the industry due to short processing times and a variety of shipping methods. Your orders are packaged at one of the many local warehouses across the country, minimizing delivery times and ensuring you get your purchases as soon as possible.PaymentsNewegg has partnered with PayPal to offer you the very best in payment services. PayPal allows you to buy with confidence, knowing your payments are processed quickly and securely with state-of-the-art encryption technology.ReturnReturns are subject to restocking fees of 15% - 30% of the purchase price and return shipping fees. For products that are eligible for return for replacement, the return shipping labels are free for returns for replacement of the same item within the applicable return policy period. Newegg does NOT charge for restocking fees or return shipping labels for returns of defective products, or if you received the wrong product, the product did not match what was shown on the Site, or we made some other shipping error, provided the item is returned within its return policy period, and in accordance with the Return Policy. For international buyers, items shipped internationally do not qualify for manufacturer warranties.
