Dual 4K Display on Mac

Using a Mac with an M4; M5 or M3; or any Pro/Max CPU; extend your desktop to 2x screens using any combination of HDMI and/or DisplayPort. Macs with a base M1 / M2 CPU only support one external display; while the M3 can support up to two external displays with the lid closed while running up to date macOS. This laptop docking station dual monitor solution ensures seamless multi-screen productivity.

Quad 4K Display on Windows

With this Thunderbolt 4 docking station Windows Thunderbolt 4 and USB4 computers can use the 2x HDMI ports; and 2x DisplayPort ports to connect as many as 4x screens at up to 4K 60Hz. Can also be used as a single; dual; or triple display docking station. Windows Thunderbolt 3 and USB-C laptops can support up to dual displays.

100W Power Delivery

The laptop Thunderbolt docking station offers USB Power Delivery up to 100W (98W certified) - no more climbing under the desk to get plugged in. Not all laptop docking stations handle power the same. With the TBT4-UDZ; if your laptop needs less power; the docking station adjusts and only sends the optimal wattage. And with 6x available USB ports; and one USB-C port; your devices will always have a place to connect.

16 Ports to Power Productivity

The TBT4-UDZ has all the ports you need: 2x HDMI; 2x DisplayPort; 1x Thunderbolt 4 (to host); 1x USB-C (10Gbps); 3x USB (10Gbps); 2x USB (5Gbps); 1x USB 2.0 (charging); SD and microSD Card Slots; Audio In/Out; Gigabit Ethernet TBT4-UDZ is compatible with Windows 10+ and macOS 11+. Connect via Thunderbolt 4/3; USB4 or USB-C via included Thunderbolt 4 cable (40Gbps; 3.3ft/1m). Actual number of screens that can be extended depends on the capabilities of the host computer.

Product Features:

• Award Winning Plugable Thunderbolt 4 Dock - Premium 16-in-1 design enables dual 4K 60Hz screens on M4/M5 Macs; Windows and USB4. Laptop Mag 2025 Dock of the Year with 7 USB ports; 2.5Gbps Ethernet; SD/microSD slots; audio; and 100W charging
• Seamless Dual Monitor Setup for M4/M5 Macs - This dual monitor for laptop docking station enables two 4K 60Hz displays via HDMI or DisplayPort-no drivers needed. Just plug and play. Also supports Windows Thunderbolt 4/USB4 laptops
• 100W Power Delivery - Ensure all-day laptop charging with 100W Power Delivery. Third party lab tested to UL standards for safe; worry-free charging. Automatically adjusts for lower power systems and provides USB-C and USB ports for peripheral charging
• Universal Compatibility - Works with Thunderbolt 5; Thunderbolt 4; USB4; and USB-C laptops. Compatible with macOS 11+ and Windows 10 or later. This dual monitor docking station connects effortlessly with the included Thunderbolt 4 cable (40Gbps; 3.3ft/1m)
• Boost Productivity - Turn your laptop into a powerful dual monitor workstation with this dual monitor thunderbolt dock. Perfect for multitasking; content creation; and professional workflows - perfect for Mac users needing a clean; simple dual-monitor Cables
  • Port Type (Side 1): Male Thunderbolt 4 or Thunderbolt 3 or USB-C
  • Cable Specification: Thunderbolt 4 (40Gbps)
  • Port Type (Side 2): Thunderbolt 4 or Thunderbolt 3 or USB-C
  • Cable Length: 1.0m/3.28ft
  • External Power for Cable: No

  LEDs

  • LED Number 1:
  • Color: White
  • Status: Solid
  • Definition: Powered on
  • LED Number 1:
  • Color: Green
  • Status: Solid
  • Definition: Powered on; active host HDMI 4K (Output):
  • Placement: Rear
  • Specification: HDMI 2.0
  • Max Resolution and Refresh Rate: 4096x2160 60Hz; 3840x2160 60Hz; 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 4096x2160 60Hz
  • HDCP: Supported
  • Chipset: RTD2188-VA-CG Realtek
  • 2x DisplayPort (Output):
  • Placement: Rear
  • Specification: DisplayPort 1.2
  • Max Resolution and Refresh Rate: 4096x2160 60Hz; 3840x2160 60Hz; 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 4096x2160 60Hz
  • HDCP: Supported
  • Chipset: RTD2188-VA-CG Realtek

  Video Output Modes

  • DisplayPort 1.4:
  • Host Port Type: Thunderbolt 4
  • Number of Displays Used: 1; 2; 3; or 4
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.2:
  • Host Port Type: Thunderbolt 3 (Two Display Streams)
  • Number of Displays Used: 1 or 2
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.2:
  • Host Port Type: Thunderbolt 3 (Single Display Stream)
  • Number of Displays Used: 1
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.4:
  • Host Port Type: USB-C (with Alt Mode and MFDP)
  • Number of Displays Used: 1 or 2
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.4:
  • Host Port Type: USB-C (with Alt Mode)
  • Number of Displays Used: 1 or 2
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.2:
  • Host Port Type: USB-C (with Alt Mode and MFDP)
  • Number of Displays Used: 1 or 2
  • Max Resolution at Display Count: 1920x1080 50Hz; 1920x1080 30Hz; 1920x1080 25Hz; 1920x1080 24Hz; 1280x720 60Hz; 1280x720 50Hz; 720x480 60Hz; 720x576 50Hz; 1920x1080 60Hz
  • DisplayPort 1.2:
  • Host Port Type: USB-C (with Alt Mode and MFDP)
  • Number of Displays Used: 1
  • Max Resolution at Display Count: 3840x1600 60Hz; 3440x1440 60Hz; 2560x1440 60Hz; 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 60Hz
  • DisplayPort 1.2:
  • Host Port Type: USB-C (with Alt Mode)
  • Number of Displays Used: 1
  • Max Resolution at Display Count: 3840x1600 30Hz; 3440x1440 30Hz; 2560x1440 60Hz 1920x1080 60Hz; 1600x900 60Hz; 1280x1024 60Hz; 1280x800 60Hz; 1280x720 60Hz; 1152x864 60Hz; 1024x768 60Hz; 800x600 60Hz; 640x480 60Hz; 3840x2160 4K Output:
  • Placement: Rear
  • Connection: DisplayPort
  • Max Bit Depth and Sample Rate: Host Dependent
  • Signal Output: Digital
  • Channels: Host Dependent
  • DisplayPort Output:
  • Placement: Rear
  • Connection: DisplayPort
  • Max Bit Depth and Sample Rate: Host Dependent
  • Signal Output: Digital
  • Channels: Host Dependent
  • Headset Jack Bi-Directional:
  • Placement: Front
  • Connection: 3.5mm (TRRS)
  • Max Bit Depth and Sample Rate: 16-bit 48KHz
  • Signal Output: Analog
  • Channels: 2
  • Chipset: ALC4030U Supply:
  • Placement: Rear
  • Power Host / Device: Device
  • Connection Type: Region-specific Power Adapter
  • Notes: UL 60950-1 Certified
  • Voltage: 20.0V
  • Amperage: 6.75A
  • Wattage: 135.0W
  • Thunderbolt 4 to Host:
  • Placement: Front
  • Power Host / Device: Host
  • Connection Type: USB-C Power Delivery
  • Voltage: 20.0V
  • Amperage: 4.9A
  • Wattage: 98.0W

  USB To Devices

  • 1x USB-A:
  • Placement: Front
  • Version and Link Rate: USB 2.0 (480Mbps)
  • Features: Battery Charging 1.2
  • Voltage: 5V
  • Amperage: 1500mA
  • Wattage: 7.5W
  • 1x USB-A:
  • Placement: Front
  • Version and Link Rate: USB 3.2 Gen 2 (10Gbps)
  • Voltage: 5V
  • Amperage: 900mA
  • Wattage: 4.5W
  • 1x USB-C:
  • Placement: Rear
  • Version and Link Rate: USB 3.2 Gen 2 (10Gbps)
  • Features: USB Power Delivery
  • Voltage: 5V
  • Amperage: 1500mA
  • Wattage: 7.5W
  • 2x USB-A:
  • Placement: Rear
  • Version and Link Rate: USB 3.2 Gen 2 (10Gbps)
  • Voltage: 5V
  • Amperage: 900mA
  • Wattage: 4.5W
  • 2x USB-A:
  • Placement: Rear
  • Version and Link Rate: USB 3.0 (5Gbps)
  • Voltage: 5V
  • Amperage: 900mA
  • Wattage: 4.5W

  Connection To Host

  • Port: 1x Thunderbolt 4 or Thunderbolt 3 or USB-C
  • Placement: Front
  • Version and Link Rate: Thunderbolt 4 (40Gbps)
  • Features: 4x PCIe 3.0 Lanes or USB Power Delivery or Alternate Mode Video

  Wired Network

  • Port: 2.5 Gigabit Ethernet
  • Placement: Rear
  • Version and Link Rate: 2.5GBASE-T
  • Features: Wake-on-LAN (WoL) or Energy-Efficient Ethernet (EEE) or 9K Jumbo Frames
  • Chipset: RTL8156B Realtek

  Card Reader

  • Micro SD:
  • Bus Interface: Ultra-High Speed II (UHS-II)
  • Bus Speed: 312 MB/s
  • Chipset: Genesys Logic GL3231S
  • SD or SDHC or SDXC or MMC:
  • Bus Interface: Ultra-High Speed II (UHS-II)
  • Bus Speed: 312 MB/s
  • Chipset: Genesys Logic GL3231S

  Physical Stats

  • Size (H x W x D) or Length: 3.5 x 10.5 x 19.5 centimeters (1.4 x 4.1 x 7.7 in.)
  • Weight: 646 grams (22.8 ounces)
  SPECIFICATIONS More Product Information for the Plugable Technologies Thunderbolt 4 16-in-1 Dock Station for MacBook Air/Pro - TBT4-UDZ


  The Thunderbolt Certified 16-in-1 Quad docking station from Plugable delivers peak performance. The innovation starts with our display connections. Connect your 4K screens through 2x HDMI ports and 2x DisplayPort ports - a rare level of display flexibility in a Thunderbolt dock. But the real expansion picks up at the ports. Offering sixteen total ports to park your peripherals, including 7x USB ports, SD and microSD card readers, Audio, and 2.5Gbps Ethernet. It even adapts to your desk with an included stand for vertical or horizontal orientation options.

  Quad Display


  With this Thunderbolt 4 docking station Windows computers can use the 2x HDMI ports, and 2x DisplayPort ports to connect as many as 4x screens at up to 4K 60Hz. Can also be used a single, dual, or triple display docking station.

  On Mac (Intel, M1 Pro/Max CPU), extend your desktop to 2x screens using any combination of HDMI and/or DisplayPort. Macs with an M1 or M2 CPU only support one external display.

  Charge Up with 100W Power Delivery


  The laptop Thunderbolt docking station offers USB Power Delivery up to 100W (98W certified) - no more climbing under the desk to get plugged in.

  Not all laptop docking stations handle power the same. With the TBT4-UDZ, if your laptop needs less power, the docking station adjusts and only sends the optimal wattage.

  And with 6x available USB ports, and one USB-C port, your devices will always have a place to connect.

  16 Ports to Power Productivity


  The complement of available ports on the TBT4-UDZ has you covered. From a convenient spot to plug in your phone, to waving bye-bye to the spotty wifi with 2.5Gbps Ethernet.

  Get connected with:

  • 2x HDMI
  • 2x DisplayPort
  • 1x Thunderbolt 4 (to host)
  • 1x USB-C (10Gbps)
  • 3x USB (10Gbps)
  • 2x USB (5Gbps)
  • 1x USB 2.0 (charging)
  • SD and microSD Card Slots
  • Audio In/Out
  • Gigabit Ethernet (2.5Gbps)

  Actual Ethernet port speed determined by driver version and host model.

  For best results be sure to download the latest Ethernet drivers (which can be found on the Plugable website). To reach 2.5Gbps speeds, a 2.5Gbps Ethernet switch or 2.5Gbps network router is required.


  Specifications
  General Information Manufacturer Plugable Technologies Manufacturer Part Number TBT4-UDZ Brand Name Plugable Product Model TBT4-UDZ Product Name Thunderbolt 4 & USB4 Quad Display Docking Station With 98W Charging Packaged Quantity 1 Product Type Docking Station Technical Information Connectivity Technology Wired Device Supported Desktop PC/Notebook/Monitor Memory Card Reader Yes Memory Card Supported microSD Memory Card Supported SD Memory Card Supported SDXC Memory Card Supported SDHC Memory Card Supported MultiMediaCard (MMC) Number of Displays Supported 4 Screen Mode Supported 4K Supported Resolutions 3840 x 2160 Network & Communication Ethernet Technology 2.5 Gigabit Ethernet Interfaces/Ports Host Interface Thunderbolt 4 Host Interface USB Type C Total Number of USB Ports 7 Number of USB 2.0 Ports 1 Number of USB 3.0 Ports 2 Number of USB 3.2 Gen 2 Type-A Ports 3 Number of USB Type-A Ports 6 USB Type-A Yes USB Type-C Yes USB Type-C Detail 1 x USB-C, Rear, USB 3.2 Gen 2 (10Gbps) Network (RJ-45) Yes Number of RJ-45 Ports 1 Number of DisplayPort Outputs 2 DisplayPort Yes Headphone/Microphone Combo Port Yes Number of HDMI Outputs 2 HDMI Yes Thunderbolt Yes Software Operating System Supported Windows 10 Operating System Supported macOS Big Sur Operating System Supported Windows 11 Power Description Maximum Power Supply Wattage 98 W Miscellaneous Package Contents
  • Thunderbolt 4 & USB4 Quad Display Docking Station With 98W Charging
  • 1 x Quick Start Guide
  • 1 x Power Supply
  • 1 x Power Cable
  • 1 x Vertical Stand
  • 1 x 1.0m 40 Gbps Thunderbolt 4 Cable
  Compatibility Apple MacBook Brand Compatibility Apple IN THE BOX
