QLogic QLE2742
Dual‑Port 32Gb Gen6 Fibre Channel HBA, PCI‑E 3.1 x8 SFP+ Host Bus Adapter
Product Overview
The QLE2742 is Marvell QLogic Gen6 32Gb Fibre Channel dual‑port host bus adapter (HBA), built for enterprise SAN storage environments. Delivering industry‑leading low‑latency storage connectivity, it supports FC‑NVMe and traditional SCSI‑FCP workloads. Full‑hardware offload reduces CPU overhead significantly. Backward compatible with 16Gb /8Gb Fibre‑Channel fabrics, it protects existing SAN infrastructure investment. Widely available aftermarket as new‑surplus, refurbished and server‑pull used units.
Key Features
- Model: QLE2742 (QLE2742‑SR‑CK with SR transceivers)
- Ports: 2 × SFP+ slots for 32Gb Fibre‑Channel optical modules
- Line‑rate speed: 32 Gbps per port, backward auto‑negotiate 16Gb / 8Gb FC
- Host interface: PCI‑Express 3.1 x8 (8.0 GT/s)
- Protocol support: FC‑NVMe, SCSI‑FCP, FC‑Tape, NPIV port virtualization for VM deployments
- High performance: Up to 650 K IOPS per port, ultra‑low latency under 1 microsecond
- Hardware offload: Full FC processing offload to free server CPU resources
- Diagnostic: ClearLink D‑Port for cable and link health validation
- Management: QConvergeConsole GUI / CLI management utility, SNIA‑HBA‑API, SMI‑S support
- Boot capability: BIOS & UEFI remote SAN boot
- Form‑factor: Low‑profile adapter; full‑height bracket included
- Transceivers: SFP+ modules optional (some SKUs ship with 32G‑SR optics)
Technical Specifications
- Typical power consumption: < 12 W dual‑port full load
- Operating temperature: 0 °C ~ +55 °C (server forced airflow required)
- Storage temperature: −20 °C ~ +70 °C
- Humidity: 10‑90 % non‑condensing
- Interrupt: MSI‑X, MSI, INTx
- Supported OS: Linux, Windows Server, VMware ESXi, major OEM validated hypervisors
- Compliance: FCC Class‑A, CE, UL, RoHS
Ordering & Condition Notes
- Part number: QLE2742, QLE2742‑SR‑CK (with SR transceivers)
- Status: Mature enterprise Gen6 FC adapter, widely used for SAN refresh projects
- Warranty: Original manufacturer warranty only applies to brand‑new sealed retail units. Used / pulled stock carries no OEM warranty. Available as new‑surplus, refurbished, pre‑owned server pulls.
- Note: SFP+ optical transceivers are not always included, verify listing contents.
Typical Applications
Enterprise SAN storage access, FC‑NVMe all‑flash‑array connectivity, virtualization hosts, database servers, backup & tape library environments, hyper‑converged infrastructure, mission‑critical data‑center storage networks.
