› ‹ › ‹ › ‹ › ‹ › ‹ › ‹ › ‹ › ‹ › ‹ › ‹ › ‹ Rare AT PSU - 300W with P8, P9 and Optional P10 Connectors Available See ratings
- Rare 300W AT power supply (ATX PSU + AT adaptor) for legacy AT systems, kiosks and industrial machines
- Flat white P8 and P9 6-pin motherboard connectors, plus Molex, SATA and Floppy connectors
- Optional 6-pin P10 connector available (+3.3V orange or +5V red) - select the connector options you need
High Quality / Returns Accepted / 2 Year Warranty on PSUs
Product Description
AT 300W PSU with P8, P9 and P10 Connectors - Rare Legacy PSU. Rare, alternative AT power supply unit (ATX PSU + AT adaptor) delivering reliable power for legacy systems built on AT technology. Specifically designed for vintage computing applications, kiosks, arcade machines and industrial control systems. Full-range 115-230V input with manual voltage switch.
Looking for a genuine AT PSU instead? This listing is a modern ATX PSU with an AT adaptor supplying the P8 and P9 connectors. If you specifically need a genuine (original) AT power supply rather than this replacement, please visit our store or contact us - we stock genuine AT PSUs too. Key Features
- P8 & P9 Connectors - flat white 6-pin motherboard connectors via AT adaptor
- 300W Output Power - reliable power for legacy AT systems
- Multiple Molex & SATA - Molex peripheral connectors plus modern SATA support
- Remote ON/OFF Switch - convenient system power control, self-latching and replaceable
- Optional P10 Connector - 6-pin P10 available on request (+3.3V orange or +5V red)
- 80mm Cooling Fan - reliable airflow for continuous operation
- 2-Year Warranty - 1 year standard + 1 year free extended warranty, 30-day returns if unwanted
- Brand New, UK Shipped - dispatched from the United Kingdom, free UK delivery on all orders
Please read before installation:
- P8 and P9 connectors must be plugged in so the black wires sit side by side, together in the centre.
- Some systems without motherboards do not require the P8 & P9 connectors, which can be left unused.
- Some systems do not require the On/Off switch - it can be left switched ON and tied up safely inside the machine.
- Supplied with a large latching switch suitable for most AT systems. It is removable and can be replaced (terminal block size: 9x0.6mm). Check the diagram on the PSU for correct wiring - an incorrect connection will damage the PSU.
- Some AT PSUs come with an additional 6-pin P10 connector (three black wires plus three +3.3V orange or three +5V red wires). Select the optional P10 connector if required - more than one can be ordered. Not sure if this is the right PSU? Check your model against the Compatibility List below, or contact us with your old PSU model number and a photo - we're happy to help find the right match. Technical Specifications Model NumberFSP300-60PLN(AT). Model number may vary. AC Input115-230V. Suitable worldwide, with manual voltage switch. Select the suitable voltage BEFORE using the PSU to prevent damage. Power Output300 Watt Form FactorAT ColourGrey Ventilation1x 80mm fan Product Size & Weight85 x 150 x 140mm / 3.3 x 5.9 x 5.5 inch / 1.4kg Connectors Molex4x Molex connectors SATA4x SATA connectors Floppy (Berg)1x Floppy Drive Berg connector 6-pin P8 & P9P8 & P9 with standard AT wiring. Note that some PSUs have a slightly different colour wiring even though the voltages are the same. 6-pin P10 (optional)Optional rare P10 connector with +3.3V orange wires (standard) or +5V red wires. Check your requirements and select the suitable option if required. More than one P10 connector can be ordered. DC Output +12V115A +5V30A -12V0.8A -5V0.3A More Info Package Size & Weight100 x 250 x 200mm / 3.9 x 9.8 x 7.9 inch / 1.7kg Product ConditionBrand new Warranty1 year standard + 1 year free extended = 2 year warranty ReturnReturn accepted within 30 days if unwanted Made InChina Shipped FromUnited Kingdom RemarksP8 and P9 connectors are supplied as an adaptor and MUST be plugged in so that the black wires are side by side (together in the centre) - see illustration in the gallery above. Compatibility List
Browse the PSU models this unit replaces, and the systems it is compatible with. Use your browser's Ctrl+F (or Cmd+F on Mac) to search this page for your model.
Compatible power supplies:
- Ace-940AP
- Acer Aspire 5133LK
- ADT-925C
- AGI BPS-2001-4U
- AGI BPS-2504-4U
- AGI PS-250W
- Arbor ZKS-250AE
- Astec 190170-01
- Astec 213-00013
- Astec 628699-001
- Astec 73-610-001
- Astec 73-610-016
- Astec PSE5-115-CI-001
- Astec PSE5-115-CI-016
- Astec SA145-3408
- Astec SA145-3430
- Astec SA145-3490
- Astec SA201-3438
- Astec SA201-3439
- Astec SA201-3440
- Astec SA201-3455
- Astec SA301-3405
- Astec SA302-3505
- Astec VL201-3400
- Athena Power AP-AT30
- Athena Power AP-AT35
- Athena Power AP-AT40
- Athena Power AT-30
- Bestec BPS-2504-4TU
- Bestec BPS-2994-4U
- Compaq 213928-001
- Compaq 213929-001
- Compaq 213976-021
- Compaq 214969-001
- Compaq 214978-001
- Compaq 334540-001
- Compaq 334543-001
- Compaq Presario 5695
- Compaq PS2021
- Compaq PS-5151-4A
- Compaq PS-5151-4C
- Deer DR-230C
- Delta DPS-145PB-38 A
- Delta DPS-145PB-38 A Rev: 01
- Delta DPS-200PB-8
- DVE DSP-1454C
- DVE DSP-1454P
- DVE DSP-1514P
- Emacs HG2-6300P (AT)
- Emacs SP2-4250F
- Emacs SP2-4300FB 6SP2-300B054
- Enermax E251P-V
- FS200 S40G
- FSP 9PP2500201
- FSP 9PP2500203
- FSP SPI-250G
- FSP SPI-300G
- Gateway 6500010
- G-Power 190308-01
- G-Power GP-4150PB
- G-Power GP-4200PB
- GT-230W
- Hipro HP-200 PPGN
- Hipro HP-230PPFN
- IBM 52G7955
- IBM 92F0411
- Kingspao KP-220TUL
- Kingspao MPS-6220T
- KP-230WN
- Liteon PA-4221-3A1
- Liteon PA-4151-9B1
- Liteon PS-5151-4A
- Liteon PS-5151-4C
- Macase MG-250EP
- Mapower PP-300TA (no P8&P9)
- Max Power KP-220TUL
- Max Power MPS-6220T
- NEC 158-050684-002
- NEC 190170-01
- NEC 213-00007
- NEC SA302-3505-1276
- Packard Bell 190050
- Packard Bell DSP-1454P
- Packard Bell PB150C
- Power Switch Corp PS-AT-200CC
- Power Tronic PTA-4200CF
- Power Tronic SK-4145DE
- PowerMan HP-230PP3
- PowerWin PW-250APSA
- PowerWin PW-200APSA
- Ram Technologies PFC230PC
- PSA-2054C
- RA-4022A
- SB250PL
- Sentomi SMP-200V
- Seventeam ST-300WHT-P
- Sparkle 9PP2500201
- Sparkle 9PP2500203
- Sparkle SPI-250G
- Sparkle SPI-250G-B
- Sparkle SPI-300G
- Sparkle SPI-300G-B
- SPI-200G
- SPI-250G
- SPI-300G
- SPQ-4300
- SPQ-4400
- SQH-4204
- ST-230WHF
- StarTech AG-230T
- StarTech PS2POWER230
- Topower TOP-250SS
- Topower TOP-250SS-CE
- Touch MU-250P
- Zippy Emacs HG2-6300P
And more...
Compatible systems:
- Older legacy computers using AT technology
- HDD storage enclosures
- Shopping mall kiosks
- Legacy industrial control platforms
- Plant control systems
- Amusement industry: gaming machines, video games, arcade games
- Merit Megatouch XL (Gold, Platinum, and Titanium)
- Merit Scorpion Dart
- WMS Pin2000
- Arachnid Black Widow
- Benchmark Big Haul
- Valley HB & IQ Dart
- Merit Maxx
And more...
Can't find your model? This list covers the most common compatible units but is not exhaustive. Contact us with your PSU model number and a photo and we will confirm compatibility for you.
