Shiping within 24 hours via UPS Ground!!Our store offersexpedited shippingvia UPS(2nd Day Air or Next Day Air)，and shipping toAlaska/Hawaii/Puerto Rico/ Virgin Islands/ GuamPlease contact us in advance if you require these SeriesModelHIVE-750SDetailsTypeATX12V v2.31 / EPS12V v2.92Maximum Power750 WFans1 x Silent 135mm Fan (Auto Speed Control)PFCActiveMain Connector20+4Pin+12V RailsSinglePCI-Express Connector4 x 6+2-PinSATA Power Connector8SLISLI ReadyHaswell SupportYesCrossFireCrossFire ReadyMax PSU Length160 mmModularFull ModularPower Good Signal100-500msHold-up Time16ms min.Efficiency> 85%Energy-Efficient80 PLUS BRONZE CertifiedOver Voltage ProtectionYesInput Voltage100 - 240 VInput Frequency Range50/60 HzInput Current10A - 6.3AOutput+3.3V @ 22A, +5V @ 22A, +12V @ 62.5A, -12V @ 0.5A, +5VSB @ 3AMTBF100,000 hour(s) at 25 Celsius degrees, max. load, nominal inputApprovalsTUV, cTUVus, CE, FCC certifiedConnectorsModular Cables:
1 x 20+4-Pin Main Connector
2 x 4+4-Pin CPU Connector
4 x 6+2-Pin PCI-E Connector
8 x SATA Connector
6 x 4-Pin Peripheral Connector
1 x 4-Pin Floppy ConnectorCable Spec20+4Pin MB: One cable (550mm)
4+4Pin CPU: Two cables (600mm)
2 x PCI-E 6+2Pin: Two cables (600, 750mm)
4 x SATA: One cable (550, 700, 850, 1000mm)
2 x SATA + 2 x Molex: Two cables (550, 700, 850, 1000mm)
1 x FDD: One cable (150mm)FeaturesFeatures80 PLUS BRONZE CertifiedContinuous 750W at 40 degrees CelsiusSingle strong 12V rail - ideal for Gaming systemSLI & CrossFire ready - 4 x 6+2-Pin Connector1 x Silent 135mm Fan with auto fan speed controlActive-PFC with auto AC-input voltage adjustment (100 - 240V)Mesh sleeve on all cables for easier cable routing and better ventilationOver Temperature / Current / Voltage / Power Protection, Under Voltage Protection, and Short Circuit Protection provide maximum safety to your critical system componentsTUV, FCC, CE CertificatedDimension & WeightDimensions3.36" x 5.91" x 6.30"Weight5.90 lbs.
