Product Features
HDMI DISTRIBUTER: Distributes HDMI video and audio from a single source to up to 8 HDMI displays simultaneously while maintaining signal quality. Compliant with HDMI 2.0a, HDCP 2.2/1.4 with 18Gbps bandwidth.*SUPPORTS up to 4K @60Hz (YUV 4:4:4 8-bit), HDR 4K @60Hz (YUV 4:2:0 10bit), 3D, xvYCC, x.vlor & Deep Color. Supports 7.1/5.1/2.1 Ch., Dolby Digital, DTS-HD, and Dolby TrueHD audio. Works with Apple TV, Roku, Fire TV, PS4, Blu-Ray, Nvidia Shield.*AUTO VIDEO SCALING FEATURE: Detects and configures the video resolution automatically according to the capabilities of each connected monitor. Supports simultaneous 4K and 1080P output. See notes below for limitations.*CASCADABLE: Easy to cascade mulptiple splitters for more displays, and supports up to 10 layers. EDID and firmware management feature for maximum compatibility now and into the future, offers widest range of monitor/display/TV support from either pre-programmed EDID or EDID learning from the connected displays.*LOW HEAT GENERATION AND ESD PROTECTION to guarantee stability and reliable performance. Sturdy metal housing provides excellent heat dissipation, durability, and minimizes EMI/RFI noise interference. Made in Taiwan with 3 YEARS warranty backed by US based experienced tech support team. Please contact us directly if you have any questions or 2.0 & HDCP 2.2 compliant-supports xvYCC, x.Vlor & Deep color-supports resolution down scaling from 4K to 1080p. *See es below for limitations
-video bandwidth: 18Gbps (single-link 600MHz)-display modern: mirror- ESD protection: 15KV Air/ 8KV contact-LED indication for power and signal
-supports cascading of multiple splitters for adding more displays, supports up to 10 layersgame capture in 1080p while playing in 4k!
use Elgato or other game capture device to record game play footage in 1080p, while actually playing in 4K!maximum resolution:
-3840X2160@60Hz (yuv 4: 4: 4)-HDR 3840X2160@60Hz (yuv 4: 2: 0)important es: below are limitations associated with 4K content down scaling:-down scaling to 720p and 480p is supported
-yuv 4: 2: 2 down scaling is supported
-frame rate conversion (E.G., 60Hz to 24Hz) is supported
-4k@30hz monitors will display in 1080P@60Hz when the source content is 4K@60Hz-The distribution amplifier can bypass 4K HDR data content but can process It to make 4K HDR content fit 1080p proportionally
system requirements:
-HDMI source device such as computers, game consoles, Blu-ray/DVD players, and media players
-HDMI displays, monitors, and HD TVspackage contents:
-1x8 HDMI 2.0 HDR distribution amplifier with EDID management - 4kx2k 60Hz-power adapter
-screw kit-user Reference guide
