SUNHANS 5G-5.8Ghz 4W Wi-Fi Signal Booster
Wireless LAN Indoor Signal AmplifierRelevant Wi-Fi boosters is designed for use in mobile and/or mesh wireless networking applications. Designed for bi-directional signal amplification, In contrast, traditional analog amplifier technologies can go
into saturation or reduce transmit power as input signal fluctuates, negatively impacting signal quality and network performance. This booster can be used any 5GHz antenna that implements an SMA-Male
connector. Small footprint and low profile design make it an ideal solution for mounting on vehicles, drones, or in other space-constrained applications.Relevant 5.8GHz WiFi boosters are widely used to increase the power & the signal for different products, including:
- Routers
- Access points
- IP cameras and surveillance system
- Video senders
- Professional video cameras
- RC UAV, helicopters, planes and vehicles
Booster Specifications
Model SH58Gi4000
Operating range 5000~5875MHz
Channel width 20Mhz & 40Mhz & 80Mhz
Supported standards IEEE 802.11a/n
Operation mode Bi-directional, half-duplex, time division duplex
Connector type To radio SMA female (hole inside); To antenna RP-SMA female (pin inside)
Output power 4000mW (36dBm)
Input power 0 ~ 20dBm
Transmit gain 18 - 20dB
Receiver gain 11 – 14dB
Noise figure ≤3.5dB typical
Frequency response ±1dB over operating range
Power adapter 12V/2A DC, 100~240V
Operating temperature -20°c to +70°c
Operating humidity Up to 75% relative humidity
Material Cast aluminum
LED light Power status LED and activity status LED
Booster weight 133g
Booster size 9.7 x 6.4 x 1.7cm
Antenna Specifications
5.8GHz 6dBi omni whip antenna for WiFi Router/Booster
Compliant with 802.11a/n
Frequency Range 5100-5850MHz
Bandwidth 750MHz
Gain 6dBi
VSWR ≤1.8
Polarization Vertical
Impedance 50Ω
Max power 50W
Lightning protection DC ground
Connection RP SMA
Product Size Φ1.35*20.5cm
Product Weight 30g
Color white
Cable Specifications
Cable Type RG316 Coaxial cable pigtail
Length 20cm
Impedanece 50Ω
Connectors SMA male to RP-SMA male
Packing
Package size: 420g
Package weight: 21.3 x 13.5 x 5cm
Package Includes:
1 xSH58Gi4000 WiFi booster
1 x RG316 cable with SMA connectors (20cm)
1 x 6dBi omni antenna
1 x power supply (AC/DC Power adapter)
1 x user manual
Attention:
The power amplifier is not suitable for use in high power devices
Use
Step 01: Remove the Antenna from the Wireless Router (Access Point).
Step 02: Use this cable (RG316) to connect Amplifier 'input' port with router 'output' port: note that cable is in standard spec.
Step 03: Connect the antenna with 'output' port of Amplifier.
Step 04: Power the amplifier with the matching source adapter.
