Key Features
- 4K UHD (3840 x 2160) Native Resolution
- 8 ms Response Time
- 4000:1 Contrast Ratio
- Built-In Wi-Fi & Ethernet Connectivity
- DVI-D, DisplayPort, 2 x HDMI 2.0 Inputs
- USB Multimedia Playback
- SSSP with Tizen 4.0 OS
- Dual Built-In 10W Speakers
- Digital Signage Capable
Display Size98"Native Resolution3840 x 2160Maximum Brightness350 nits / cd/m2Inputs2x HDMI 2.0
1x DisplayPort 1.2
1x DVI-D
1x 1/8" / 3.5 mmShowMoreOutputs1x HDMI 2.0
1x 1/8" / 3.5 mm (Analog Audio)USB I/O2x USB-A 2.0 (Audio/Photo/Video/Charging)Ethernet I/O1x RJ45 (Unspecified Ethernet)Other I/O1x 1/8" / 3.5 mm Serial (RS-232C) Input/Output
1x 1/8" / 3.5 mm IR InputBuilt-In SpeakersYes, 2x 10 WMedia Card ReaderNoDisplayDisplay Size98"Panel TypeLCDAspect Ratio16:9Display OrientationLandscape, PortraitNative Resolution3840 x 2160Maximum Brightness350 nits / cd/m2Lighting SystemDirect LEDContrast Ratio1200:1Response Time8 ms (GtG)Refresh Rate60 HzViewing Angle (H x V)178 x 178°Screen Area84.994 x 47.809" / 2158.848 x 1214.352mmHorizontal Frequency30 to 81 kHzVertical Frequency48 to 75 HzPixels Per Inch (ppi)45 ppiSurfaceHaze Level25%VideoTV TunerNoConnectivityInputs2x HDMI 2.0
1x DisplayPort 1.2
1x DVI-D
1x 1/8" / 3.5 mmOutputs1x HDMI 2.0
1x 1/8" / 3.5 mm (Analog Audio)HDCP SupportYes, Version 2.2USB I/O2x USB-A 2.0 (Audio/Photo/Video/Charging)Ethernet I/O1x RJ45 (Unspecified Ethernet)Other I/O1x 1/8" / 3.5 mm Serial (RS-232C) Input/Output
1x 1/8" / 3.5 mm IR InputSpeakerBuilt-In SpeakersYes, 2x 10 WSpeaker Configuration2-ChannelHardwareSmart TVTizen 4.0CPUQuad-Core:Up to 1.7 GHz Cortex A72Storage8 GBRAM2.5 GB LPDDR4 1500 MHzMobile App CompatibleNoMedia Card ReaderNoBuilt-In MicNoSupported File FormatsSupported Video File TypesH.263, H.264/AVC, H.265/HEVC, MPEG, MPEG2, MPEG4, VC-1, VP8, VP9Supported Audio File TypesAC3Supported Photo File TypesJPEG, PNGElectricalPower ConsumptionTypical: 360.0 W
Maximum: 462.0 W
Standby: 0.5 WInput Power100 to 240 VAC, 50 / 60 HzGeneralOperating Conditions32 to 72°F / 0 to 40°Cat 10 to 80% HumidityMounting-Hole Pattern800 x 400 mmBezel Thickness17.9 mm (Bottom/Right/Top/Left)Duty Cycle24 Hours / 7 DaysDimensions86.4 x 49.2 x 3.8" / 2195.8 x 1250.8 x 96.5mmWeight183.0lb / 83kgPackaging InfoPackage Weight234 lbBox Dimensions (LxWxH)93 x 55 x 13.8"
