? High efficiency with 80 PLUS Gold certification

? 24/7 continuous power output with 40? operating temperature

? Class-leading single +12V rail

? Silent running 135mm fan with 18 dBA

? PCI-E 8pin and PCI-E 6pin connectors support

? Advanced fully cable management

? All-black flat cables design

? Multiple protection circuitry

Combined +3.3V & +5V
100W
Combined +12V
696W
Input Voltage
100V ~ 264V
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC (PF>0.9 at full load)
Efficiency
87% ~ 90% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection
Over current protection
Over voltage protection
Short circuit protection
Under voltage protection
Over Temperature protection
Connectors
1 x 24-Pin motherboard connector(”600mm”)
2 x 8 / 4-Pin EPS / ATX 12V connector(”750mm/150mm”)
4 x 8 / 6-Pin PCIE connector(”700mm/150mm”x2)
8 x SATA connector(”600mm /150mm / 150mm/ 150mm” x2)
3 x 4-Pin Peripheral connector(”600mm / 150mm / 150mm”)
Cooling System
Single 135mm silent fan
Form factor
ATX
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 165 mm (D)
5.91" (W) x 3.39" (H) x 6.5" (D)
Weight
1.5 Kg
Certification
80 PLUS Gold
