High system configuration versatility

Compatible with rear-facing connector motherboards

Fully perforated steel front panel

Four 140mm fans included (3 at the front, 1 at the rear)

Triple 420mm radiator support.

438mm total graphics card clearance

Front I/O includes 1 x USB Type-C, 2 x USB 3.0, 1 x Audio, 1 x Mic

Material

Steel, plastic, tempered glass

Motherboard

SSI-CEB, Extended ATX, ATX, Micro-ATX, Mini-ITX

Drive bay

External

N/A

Internal

3.5" / 2.5" x 8

3.5" / 2.5" x 2 [1]

3.5” x 1

2.5” x 3

Cooling system

Front

SST-SEA2Y-BG: (140mm x 3 black fans included)

Rear

SST-SEA2Y-BG: (140mm x 1 black fans included)

Top

120mm x 3 / 140mm x 3

Bottom

120mm x 1 / 140mm x 1

Side

120mm x 3 / 140mm x 3 [2]

Internal

120mm x 2

Radiator support

Front

120mm / 140mm / 240mm / 280mm / 360mm / 420mm

Rear

120mm / 140mm

Top

120mm / 140mm / 240mm / 280mm / 360mm / 420mm

Bottom

N/A

Side

120mm / 140mm / 240mm / 280mm / 360mm / 420mm [2]

Limitation of CPU cooler

190mm

Expansion slot

8

Limitation of expansion card

Length ：438mm

Power supply

Standard PS2 (ATX)

Front I/O port

USB Type-C x 1

USB 3.0 x 2

Audio x 1

Mic x 1

Dimension

244.7mm (W), x 521.4mm (H), x 538.5mm (D), 68.7 liters

9.63" (W), x 20.53" (H), x 21.2" (D), 68.7 liters

Remark

[1] One bracket should be removed if rear connector motherboards are to be installed.

[2] Cannot coexist with drive cages
