Stack effect design with 90-degree rotated motherboard layout
Supports up to XL-ATX and SSI-EEB motherboards
3 x Air Penetrator 184i PRO fans included for immense stack effect intake performance
Innovative GPU placement with 11.3° forward tilt
Support for dual power supplies
Supports up to 540mm (triple 180mm) liquid cooling radiator
GPU & CPU in adjacent positions, both receiving independent cold air intake
Push button design for easy removal of side panels
Adjustable bottom fan bracket to increase airflow performance
Mandatory cable routing design
Front I/O includes USB 3.1 Gen 2 Type-C, USB 3.0 x 4 and combo audio x 1
Model No.
SST-ALF2B-G (Black)
Material
Aluminum, plastic, steel, tempered glass
Motherboard
SSI-EEB, SSI-CEB, Extended ATX, XL-ATX , ATX, Micro-ATX, Mini-ITX
Drive bay
Internal
3.5" x 4 (compatible with 2.5" x 4)
3.5" x 4
2.5" x 3
Cooling system
Front
120mm x 2 / 140mm x 2
Top
120mm x 4 / 140mm x 1
Bottom
180mm x 3 (180mm x 3 Air Penetrator 184i PRO fans included)
Radiator support
Front
120mm / 140mm / 240mm / 280mm
Top
120mm / 140mm / 240mm / 360mm / 480mm
Bottom
120mm / 140mm / 240mm / 280mm / 360mm (120mm x 3) / 360mm (180mm x 2) / 420mm / 480mm / 540mm / 560mm
Limitation of CPU cooler
205mm
Expansion slot
9+4+4
Limitation of expansion card
Length (vertical): 354mm
Length (horizontal): 604mm (with front hard drive cages removed)
Width: 209mm
Power supply
Standard PS2 (ATX) + Standard PS2 (ATX) under 1200W (Occupies the rear 4+4 expansion slots)
Limitation of PSU
220mm
Front I/O port
USB Type-C x 1
USB 3.0 x 4
Combo audio x 1
Dimension
261mm (W) x 576mm (H) x 658mm (D), 99 Liters
10.28” (W) x 22.68” (H) x 25.91” (D), 99 Liters
