￭ Supports standard SFX form factor and ATX via included bracket
￭ 300W continuous power output at 40℃ temperature rated for 24/7 operation (V2.0)
￭ 80 PLUS Bronze level efficiency (82% ~ 85% efficiency at 20% ~ 100% loading)
￭ Class-leading single +12V rail
￭ Silent running 92mm fan (V2.0)
￭ Single PCI-E 6pin connectors support
￭ Active PFC
Color Black（Lead-Free Paint）Combined +3.3V & +5V 90W (V2.0)
Combined +12V 300W / 25A (V2.0)
Input Voltage 90 - 264 VrmsInput Frequency Range 47Hz ~ 63HzPFC Active PFC（PF>0.9 at Full Load）Efficiency 82%~85%（20% to 100% loading）MTBF 100,000 hoursOperating temperature 0 ~ 40℃(V2.0)Protection Over current protectionOver voltage protectionShort circuit protectionOver power protection (V2.0 only)Under voltage protection (V2.0 only)Connectors 1 x 24 / 20-Pin motherboard connector（300mm）1 x 8 / 4-Pin EPS / ATX 12V connector（400mm）1 x 6-Pin PCIE connector（400mm）3 x SATA connector （300mm / 200mm / 100mm）2 x 4-Pin Peripheral connector （300mm / 200mm）1 x 4-Pin Floppy connector（300mm / 200mm / 200mm）Cooling System Single 92mm silent fan (V2.0)Form factor SFXNoise Level 18dBA minimum (V2.0)Dimension 125 mm (W) x 63.5 mm (H) x 100 mm (D)4.92" (W) x 2.5" (H) x 3.94" (D)Weight 1.0 kg (V2.0)Certification 80 PLUS BronzOther Includes SFX to ATX bracket for use in ATX case
Compatible with ATX12V v2.4Load Range (V2.0) +3.3V +5V +12V +5VSB -12VMax.(Amps) 16A 16A 25A 3A 0.3AMin.(Amps) 0A 0A 0.3A 0A 0ARange (%) ±5% ±5% ±5% ±5% ±10%Line Reg.(%) ±1% ±1% ±1% ±1% ±1%Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV
