￭ SFX-L form factor for use in small form factor computers
￭ 1000W continuous power output rated for 24/7 operation
￭ Class-leading single +12V rail with 83.3A
￭ High efficiency with 80 PLUS Platinum certification
￭ Silent running 120mm dual ball bearing fan with advanced semi-fanless operation
￭ 100% modular short cables with flexible flat arrays
￭ Strict ±3% voltage regulation and low ripple & noise
￭ 24/7 continuous power output with 50℃ operating temperature
￭ High quality construction with all Japanese capacitors
Model (on safety) SST-SX1000-LPTColor Black（Lead-Free Paint）Combined +3.3V & +5V 125WCombined +12V 999.6WInput Voltage 90V ~ 264VInput Frequency Range 47Hz ~ 63HzPFC Active PFC（PF>0.9 at full load）Efficiency 89% ~ 92% at 20% ~ 100% loadingMTBF 100,000 hoursOperating temperature 0°C ~ 50°CProtection Over current protectionOver power protectionOver voltage protectionShort circuit protectionOver temperature protectionConnectors 1 x 24 / 20-Pin motherboard connector（300mm）2 x 8 / 4-Pin EPS / ATX 12V connector（"400mm" x 2）6 x 8 / 6-Pin PCIE connector（"400mm / 150mm" x 3）8 x SATA connector（"300mm / 200mm / 100mm / 100mm" x 2）3 x 4-Pin Peripheral connector（300mm / 200mm / 200mm）1 x 4-Pin Floppy adapter connector（100mm）Cooling System Single 120mm dual ball bearing fanForm factor SFX-LNoise Level 0 ~ 36 dBADimension 125 mm (W) x 63.5 mm (H) x 130 mm (D)4.92" (W) x 2.5" (H) x 5.12" (D)Weight
