Open-frame steel mounting bracket

Supports 7mm or larger 2.5" SATA bays

Support for SATA revision I/II/III (1.5/3.0/6.0 Gbps)

2.5in SATA form factor housing

Supports full length M.2 NGFF (Next Generation Form Factor) SSD Solid State Drives (2230, 2242, 2260, 2280)

Compatible Drive Types (Type and Rate) M.2 (NGFF; B-Key)

Drive Installation Fixed

Interface SATA

Number of Drives 1

Supported Drive Height(s) 2230

2242

2260

2280

Performance

Hot Swap Capability No

Maximum Data Transfer Rate 6 Gbps

Type and Rate SATA III (6 Gbps)

Connector(s)

Drive Connectors 1 - M.2 (NGFF; B-Key) Receptacle

Host Connectors 1 - SATA Data & Power Combo (7+15 pin) Receptacle

Software

OS Compatibility OS independent; No software or drivers required

Environmental

Operating Temperature -40°C to 85°C (-40°F to 185°F)

Physical Characteristics

Product Height 0.3 in [7 mm]

Product Length 3.9 in [100 mm]

Product Weight 1.3 oz [38 g]

Product Width 2.8 in [70 mm]
