Key Features

1. Optimized for X13 WIO (W series) motherboards, support MB size up to 12.3" x 13.4"
2. 10 x 2.5" hot-swap SAS3/SATA drive bay
3. 10-port 1U SAS3 12Gbps Hybrid backplane, support up to 10x 2.5-inch NVMe storage devices, 4 of them are SAS3/SATA3 drives compatible.
4. 1U Redundant 860W Single Output Power Supply Platinum level, 54.5mm width
5. 2 full height expansion slot(s) , 1 low-profile expansion slot(s)
6. 4 x 40x56mm counter-rotation PWM fan(s)

Standard Parts List Part Number Qty Description Air Shroud MCP-310-11606-0B 1 Air block for 1U WIO SC116B with X13SEW Bracket MCP-240-00201-0N 1 1U WIO top-load riser card bracket for SC815B, SC116B HD Backplane BPN-NVME5-LB16A-S10 1 1U 10-port hybrid backplane for SAS3/SATA3/NVME5 storage Cable(s) CBL-0335L 1 FRONT CTL CABLE 20 PIN TO 20 PIN W/TUBE,70CM,PBF Cable(s) CBL-PWCD-0160-IS 2 PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,RoHS/REACH Part(s) MCP-120-00115-0N 1 Blank LP L-bracket with 4x4 vent holes Part(s) MCP-120-00116-0N 2 Blank FH L-bracket with 4x4 vent holes Part(s) MCP-230-00038-0N 1 Top cover with 1 mylar for SC113, 116 Part(s) MCP-270-00023-0N 1 1U SC116 chassis base(Redundant Power) Part(s) MCP-290-00173-0N 1 SC119 Intrusion assembly upgraded version (with 3rd mounting screw hole) (cable length: 47cm) Fan(s) FAN-0163L4 4 40x40x56 mm, 23.3K-20.3K RPM, Counter-rotating Fan Front Panel FPB-FP116-DU3 1 Front control board with two USB 3.0 for SC116/SC119X Cooling Fan & Accessory MCP-320-00027-0B 24 Plastic pin for 40x28, 40x56 fan Cooling Fan & Accessory MCP-320-00028-0B 1 Fan holder for 6pcs 40x56 fan, assemble-able for SC819/SC119/SC818/SC116 Cooling Fan & Accessory MCP-340-00035-0B 2 Dummy fan 40x56mm for 40x56 counter-rotating fan (cost-effective) Drive Tray(s) MCP-220-00047-0B 10 Black gen 3rd hot-swap 2.5inch HDD tray Power Distributor PDB-PT116-SL8824 1 Based on PDB-PT116-L8824 to optimize 24Pin etc cable lengths Power Supply & Accessory PWS-860P-1R2 2 1U 860W, Redundant power supply, 54.5mm width, Platinum with Power Supply & Accessory MCP-250-00009-0N 1 SC113 Redundant Power Distributor Cover Mounting Rail(s) MCP-290-00016-0N 1 1U open rack bracket set for CSE-PT51L,MCP-290-00054-0N Mounting Rail(s) MCP-290-00063-0N 1set Rail set, quick/quick, default for 1U 17.2"W for SC113/SC116,RoHS/REACH Rear Window MCP-240-00202-0N 1 1U WIO rear window to support top-load riser bracket for SC815B,SC116B
