TMC2209 V2.0 Stepper Motor Driver UART 2.5A UART Silent Drivers Stepsticks Up To 256 Subdivision for 3D Printer SKR V1.3/1.4TMC2209 V2.0 Stepper Motor Driver Silent Stepsticks Drivers Up To 256 Subdivision Support Step/Dir and Uart Mode for 3D Printers
Features:
1. Excellent Noise Reduction:The tmc2209 v2.0 stepper motor driver offers exceptional noise reduction, ensuring a quiet operation.
2. Full Compatibility with TMC2208:The 2.5a uart silent drivers stepsticks is a perfect replacement for the TMC2208, providing all the same functionalities. Additionally, it offers improved heat dissipation and supports higher current.
3. Enhanced Heat Dissipation:Equipped with a large heat sink, the silent stepsticks drivers offers excellent heat dissipation capabilities, ensuring optimal performance.
4. Sensorless response Support:The ultra silent stepsticks with heatsink supports sensorless response functionality, eliminating the need for additional sensors.
5. UART Mode Support:By simply adding a jumper cap instead of soldering, the 2.5a peak stepstick silent driver can be easily configured to support UART mode on KS Gen_IV2.0, SKR1.3/1.4, and MKS SGen_L boards.



Specification:
Origin: Mainland China
Item Type: Module
Product Size: style="color: #222222; font-family: 'TT Norms Pro', 'Open Sans', Roboto, Arial, Helvetica, sans-serif, SimSun; font-size: 14px; white-space: normal;" />Default Current: 1.25a
Maximum Current: 2.5a
Logic Voltage: 3.3v/5v
Input Voltage: 5.5v-28v
Microstep: Up to 1/256
Mode: dir/step,uart

Note:
Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
Please allow 1-2cm measuring deviation due to manual measurement.
