Features:
- 16× 10/100/1000Mbps RJ45 ports
- Innovative energy-efficient technology saves power consumption
- Supports MAC address self-learning and auto MDI/MDIX
- Standard 19-inch rack-mountable steel case
- Isolation Mode allows one-click client traffic separation for higher security and performance
- Monitor and address loop-related issues within your network structure to prevent disruptions caused by looping
- Plug and Play.No configuration or central management required.
Specification:
HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p
Interface
16× 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
Network Media
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• 100BASE-TX/1000BASE-T: UTP category 5, 5e or above cable (maximum 100m)
Physical Security Lock
Yes
Fan Quantity
Fanless
Power Supply
100-240VAC, 50/60Hz
Max Power Consumption
10.68 W (220 V / 50 Hz)
Max Heat Dissipation
36.31 BTU/h
Mounting
Rack Mountable
Dimensions (W x D x H)
17.3 × 5.5 × 1.7 in (440 × 140 × 44 mm)
PERFORMANCE
Switching Capacity
32Gbps
Packet Forwarding Rate
23.8Mpps
MAC Address Table
8K
Jumbo Frame
10KB
SOFTWARE FEATURES
Advanced Features
• Isolation Mode: Ports 1-14
• Loop Prevention: Ports 1-16
• 802.1P/DSCP QoS
• Green Ethernet technology
Transmission Method
Store and Forward
OTHERS
Certification
FCC, CE, RoHS
Package Contents
• DS1016G
• Power Cord
• Installation Guide
• Rackmount Kits
• Rubber Feet
Environment
• Operating Temperature: 0℃~40℃(32℉~104℉)
• Storage Temperature: -40℃~70℃(-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
