Standards and Protocols • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMPInterface • 2× 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)• 1× 1GE SFP WAN/LAN Ports• 8× 1GE RJ45 WAN/LAN Ports• 1× RJ45 Console Ports• 2× USB Ports (Connecting 4G/3G Modem as WAN Backup)Network Media • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)EIA/TIA-568 100Ω STP (Max 100 m)• 100BASE-TX: UTP category 5, 5e cable (Max 100 m)EIA/TIA-568 100Ω STP (Max 100 m)• 1000BASE-T: UTP category 5e, 6 cable (Max 100 m)Fan Quantity 2Button Reset ButtonPower Supply Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)PoE Budget -Flash 4MB SPI NOR + 256 MB NANDDRAM 4 GB DDR4LED PWR, SYS, WAN, LAN, USB, FANDimensions ( W x D x H ) 17.3 × 8.7 × 1.7 in (440 × 220 × 44 mm)Protection 4 kV surge protectionEnclosure SteelMounting Rack MountableMax Power Consumption • 26.36 W (with USB 3.0 connected)• 19.12 W (without USB 3.0 connected)PERFORMANCEConcurrent Session 2,300,000New Sessions /Second 20,000NAT (Static IP) • Upload: 9445.82 Mbps• Download: 9449.26 MbpsNAT(DHCP) • Upload: 9426.83 Mbps• Download: 9426.20 MbpsNAT(PPPoE) • Upload: 9413.96 Mbps• Download: 9102.01 MbpsNAT (L2TP) • Upload: 4230.62 Mbps• Download: 4169.53 MbpsNAT (PPTP) • Upload: 3933.86 Mbps• Download: 3821.97 Mbps64 Byte Packet Forwarding Rate • Upload: 1080 Mbps• Download: 1030 MbpsIPsec VPN Throughput • SHA1-AES256: 2140.45 Mbps• SHA2-AES256: 2080.20 MbpsOpenVPN 1665.64 MbpsL2TP VPN Throughput • Unencrypted: 5013.50 Mbps• Encrypted: 2274.74 MbpsPPTP VPN Throughput • Unencrypted: 3933.86 Mbps• Encrypted: 3821.97MbpsSSL VPN Throughput 1511.10 Mbps66 Byte Packet forwarding rate -1,518 Byte Packet forwarding rate • Upload: 9970 Mbps• Download: 9970 MbpsBASIC FUNCTIONSWAN Connection Type • Static/Dynamic IP• PPPoE• PPTP• L2TP• 6to4 Tunnel• Pass-Through• Mobile Broadband: 4G/3G modem for backup via USB portMAC Clone Modify WAN/LAN MAC Address*4DHCP • DHCP Server/Client• DHCP Address Reservation• Multi-net DHCP• Multi-IP InterfacesIPv6 WAN ConnectionVLAN 802.1Q VLANIPTV IGMP v2/v3 ProxyADVANCED FUNCTIONSACL IP/Port/Protocol/Domain Name FilteringAdvanced Routing • Static Routing• Policy RoutingBandwidth Control • IP/Port-based Bandwidth Control• Guarantee & Limited BandwidthLoad Balance • Intelligent Load Balance• Application Optimized Routing• Link Backup (Timing*5, Failover)• Online DetectionNAT • One-to-One NAT*5• Multi-Net NAT• Virtual Server• Port Triggering*5• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnPSecurity • SPI Firewall• VPN Passthrough• FTP/H.323/PPTP/SIP/IPsec ALG• DoS Defence, Ping of Death• Local ManagementSession Limit IP-based Session LimitVPNSSL VPN • SSL VPN Server• SSL VPN Client• 500 OpenVPN TunnelsIPsec VPN • 300 IPSec VPN Tunnels• LAN-to-LAN, Client-to-LAN• Main, Aggressive Negotiation Mode• DES, 3DES, SHA1, SHA2, AES128, AES192, AES256 Encryption Algorithm• IKE v1/v2• MD5, SHA1 Authentication Algorithm• NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS)PPTP VPN • PPTP VPN Server• PPTP VPN Client (32)*6• 300 Tunnels (Shared with L2TP)• PPTP with MPPE EncryptionL2TP VPN • L2TP VPN Server• L2TP VPN Client (32)*6• 300 Tunnels (Shared with PPTP)• L2TP over IPSecOpenVPN • OpenVPN Server• OpenVPN Client (10)*6• 110 OpenVPN TunnelsSECURITYFiltering • WEB Group Filtering*5• URL Filtering• Web Security*5ARP Inspection • Sending GARP Packets*5• ARP Scanning*5• IP-MAC Binding*5Attack Defense • TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WANAccess Control Source/Destination IP Based Access ControlAUTHENTICATIONWeb Authentication • No Authentication• Simple Password*2• Hotspot（Local User / Voucher*2 / SMS*2 / Radius*2）• External Radius Sever• External Portal Sever*2• Facebook Check-In*2• Instagram Follow*2MANAGEMENTOmada App Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.Centralized Management • Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200)• Omada Software Controller• Omada Cloud-Based ControllerCloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller.Service Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)Maintenance • Web Management Interface• Remote Management• Export & Import Configuration• SNMP v1/v2c/v3• Diagnostics (Ping & Traceroute)*5• NTP Synchronize*5• Syslog SupportZero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller.Management Features • Automatic Device Discovery• Intelligent Network Monitoring• Abnormal Event Warnings• Unified Configuration• Reboot Schedule• Captive Portal ConfigurationOTHERSCertification CE, FCC, RoHSPackage Contents • Omada 10G Multi-WAN Security Gateway ER8411• Power Cord• Rack-Mount Kit• Quick Installation GuideSystem Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11, MAC OS, NetWare, UNIX or LinuxEnvironment • Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% RH non-condensing
