HARDWARE FEATURES Plug Type US Interface 1 10/100Mbps WAN/LAN Port Reset Button
Wireless Standards IEEE 802.11b, IEEE 802.11g, IEEE 802.11n Dimensions ( W x D x H ) 3.2 x 2.8 x 1.1 in. (81 x 71 x 28mm) Antenna On-Board WIRELESS FEATURES Frequency 2.4-2.4835GHz Signal Rate 11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity Wireless Modes AP Mode, Router Mode ,Client Mode, Repeater Mode, Bridge Mode Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics
Wireless Security 64/128/152-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK Transmission Power SOFTWARE FEATURES Quality of Service WMM, Bandwidth Control WAN Type Dynamic IP/Static IP/PPPoE/PPTP/L2TP
Management Features Access Control
Local Management
Remote Managemen
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ Dynamic DNS DynDns, Comexe, NO-IP VPN Pass-Through PPTP, L2TP, IPSec (ESP Head) Access Control Local Management Control, Host List, Access Schedule, Rule Management Firewall Security DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
OTHERS Certification FCC, RoHS Package Content TL-WR700N
Resource CD
Quick Installation Guide
RJ-45 Ethernet Cable
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
