Mobile
4G LTE Cat 4 (150 DL/50 UL Mbps), 3G (21 DL/5.76 UL Mbps), 2G (236.8 DL/UL kbps), 3GPP Release 11.
Dual SIM, auto-switch for weak signal, data/SMS limit, roaming, network issues, SIM idle protection.
Status indicators: IMSI, ICCID, operator, network type, signal strength (RSSI, SINR, RSRP), data sent/received, cell ID, etc.
SMS & USSD
Supports SMS status/configuration, HTTP POST/GET, SMS auto-reply, and scheduling. USSD support for sending/receiving messages.
Wireless
802.11b/g/n Wi-Fi 4, AP/STA modes, WPA3, fast roaming, up to 100 users.
Network
Captive portal, Radius server, static/dynamic routing (BGP, OSPF, RIP), TCP/UDP, DNS over HTTPS, load balancing, failover, QoS.
Ethernet
1x WAN, 3x LAN, 10/100 Mbps, auto MDI/MDIX.
Security
Pre-shared key, X.509 certificates, firewall rules, DDOS prevention, VLAN separation, IP login blocks.
VPN
OpenVPN, IPsec, GRE, PPTP, L2TP, WireGuard, and ZeroTier supported.
Monitoring & Management
Web UI, FOTA, RMS, SSH, SNMP, MQTT, JSON-RPC, TR-069.
System Specs
580 MHz CPU, 128 MB RAM, 16 MB Flash, GNSS (GPS, GLONASS), RS232/RS485 serial ports, USB 2.0, microSD (up to 64 GB).
Power
9–30 VDC input, passive PoE, power consumption: 2 W idle, 7 W max.
Physical
110 x 50 x 100 mm, 287g, aluminum housing, DIN rail or wall mounting options.
Operating Environment
-40°C to 75°C, IP30 protection, CE, FCC, RCM, UL certified.
