McGill Microwave Introduce the New, Optimised 4G Directional Yagi Antenna – 11dBi.

The Frequency Ranges supported are 698-960MHz & 1710-2700MHz

The 4G Directional Yagi Antenna – 11dBi provides an innovative and future proof solution for 4G/3G and 2G networks.

The 4G Directional Yagi Antenna – 11dBi can take signal from multiple base stations at once, which helps to ensure continued reliable 4G reception.

The antenna has a large Vertical and Horizontal beam width for the gain that is achieved, with a 65° Vertical and 50° Horizontal beam width as a maximum.

The antenna achieves 11dBi gain as a maximum and can be used for both Outdoor and Indoor NumberMM-ANT-NF-4G-YAGI-11DBIFrequency (Deg)65/60HPBWv (Deg)50/40PolarisationVerticalInput Impedance50 OhmVSWR<1.7Maximum Power50 WattsAntenna ConnectorsN FemaleLightning ProtectionDC GroundAntenna Dimensions442 x 210 x 62mmMaterialABSColourWhiteRated Wind Speed126Km/hTemperature Range-40C/+55CMounting TypePoleWeight1.2Kg © McGill Microwave Systems Ltd All rights reserved.HomeAboutContact 4G Directional Yagi Antenna – 11dBi   McGill Microwave Introduce the New, Optimised 4G Directional Yagi Antenna – 11dBi. The Frequency Ranges supported are 698-960MHz & 1710-2700MHz The 4G Directional Yagi Antenna – 11dBi provides an innovative and future proof solution for 4G/3G and 2G networks. The 4G Directional Yagi Antenna – 11dBi can take signal from multiple base stations at once, which helps to ensure continued reliable 4G reception. The antenna has a large Vertical and Horizontal beam width for the gain that is achieved, with a 65° Vertical and 50° Horizontal beam width as a maximum. The antenna achieves 11dBi gain as a maximum and can be used for both Outdoor and Indoor use. MM-ANT-NF-4G-YAGI-11DBI Frequency Range(MHz) © McGill Microwave Systems Ltd All Related keywords yagi antenna 4g antenna directional antenna vhf yagi antenna lpda antenna yagi antennas 4g lte antenna internet antenna 4g antenna outdoor directional wifi antenna yagi wifi antenna antenna 4g wifi yagi yagi antenne yagi directional antenna 4g directional antenna 4g yagi antenna yagi antenna 4g high gain directional antenna 4g antenna sma 4g sma antenna 4g mimo antenna 4g router antenna 4g outdoor antenna antenna 4g lte sma Provided by
