📐 “𝗘𝗱𝗴𝗲” 𝗗𝗲𝘀𝗶𝗴𝗻

Slim wedge-style dock designed to sit neatly under/alongside a laptop, with most connections routed to the back for a clean setup.

🖥️ 𝗧𝗿𝗶𝗽𝗹𝗲 𝗗𝗶𝘀𝗽𝗹𝗮𝘆 𝗦𝗲𝘁𝘂𝗽 (𝗛𝗗𝗠𝗜 + 𝗛𝗗𝗠𝗜 + 𝗩𝗚𝗔)

Supports up to 3 external displays via: HDMI 1 (up to 4K@60Hz) + HDMI 2 (up to 4K@30Hz) + VGA (up to 1080p@60Hz).

Note: Additional displays may require the iVANKY “InstantView” driver on some systems; HDMI 1 is the primary plug-and-play output on supported setups.

🔋 𝗨𝗽 𝘁𝗼 𝟵𝟲𝗪 𝗟𝗮𝗽𝘁𝗼𝗽 𝗖𝗵𝗮𝗿𝗴𝗶𝗻𝗴 + 𝟭𝟴𝗪 𝗣𝗗 𝗢𝘂𝘁

Includes a 100W (20V/5A) power adapter and supports up to 96W charging through the dock (actual wattage depends on laptop and ports in use). Also includes a USB-C PD port up to 18W for phone/tablet charging.

⚡ 𝗨𝗦𝗕 data-start="1643" data-end="1804">USB 3.0 5Gbps ports for fast storage/peripherals plus USB 2.0 480Mbps ports for keyboard/mouse/dongles.

🌐 𝗚𝗶𝗴𝗮𝗯𝗶𝘁 𝗘𝘁𝗵𝗲𝗿𝗻𝗲𝘁 (𝗥𝗝𝟰𝟱)

Stable wired networking for workstations and multi-display setups.

💾 𝗦𝗗 + 𝗧𝗙 (𝗺𝗶𝗰𝗿𝗼𝗦𝗗) 𝗖𝗮𝗿𝗱 𝗥𝗲𝗮𝗱𝗲𝗿𝘀

Built-in card slots for quick file transfers.

🎧 𝟯.𝟱𝗺𝗺 𝗔𝘂𝗱𝗶𝗼 𝗝𝗮𝗰𝗸

Dedicated headset/speaker port without consuming USB.

🧠 𝗡𝗼𝘁𝗲 data-start="1643" data-end="1804">Works with supported USB-C laptops. For Windows, a USB-C 4.0 / Thunderbolt 3/4 / full-function USB-C host port is recommended for full capability.

💻 𝗟𝗮𝗽𝘁𝗼𝗽 𝗖𝗼𝗻𝗻𝗲𝗰𝘁 𝗨𝗦𝗕-𝗖: Host to laptop (data + video + charging up to 96W)

🎧 𝗔𝘂𝗱𝗶𝗼: 3.5mm headset jack

⚡ 𝗨𝗦𝗕-𝗔 𝟯.𝟬 𝗳𝗿𝗼𝗻𝘁 (x2): 5Gbps (labeled “USB 5Gbps”)

🔋 𝗗𝗖 𝗜𝗻: 20V barrel input

🔌 𝗨𝗦𝗕-𝗖 𝗣𝗗 (𝗢𝘂𝘁): PD up to 18W (5V/3A, 9V/2A) + USB 2.0 data

🖥️ 𝗛𝗗𝗠𝗜 𝟭: up to 4K@60Hz

🖥️ 𝗛𝗗𝗠𝗜 𝟮: up to 4K@30Hz

🖥️ 𝗩𝗚𝗔: up to 1080p@60Hz

🌐 𝗘𝘁𝗵𝗲𝗿𝗻𝗲𝘁: RJ45 Gigabit (1000Mbps)

💾 𝗦𝗗: SD card slot

💾 𝗧𝗙: microSD/TF card slot

🔌 𝗨𝗦𝗕-𝗔 𝟮.𝟬 𝗿𝗲𝗮𝗿 (x2): 480Mbps (labeled “USB 480Mbps”)

• 🧩 Model: iVANKY EdgeDock 3 VCD07

• 📏 Dock dimensions: 11.22 in (L) × 3.58 in (W) × 0.87 in (H)

• ⚖️ Dock weight: 484 g (≈ 1.07 lb)

• 🔌 Power adapter (included): 100W max

• ⚡ Adapter input: 100–240V~ 50/60Hz, 1.8A

• 🔋 Adapter output: 20.0V ⎓ 5.0A (100.0W)

• 🧲 DC input (dock): 20V ⎓ 5A

• 💻 Laptop charging (USB-C): up to 96W (20V ⎓ 4.8A)

• 📱 USB-C PD output: 5V ⎓ 3A / 9V ⎓ 2A (18W max)

• 🖥️ Video outputs: HDMI1 up to 4K@60Hz; HDMI2 up to 4K@30Hz; VGA up to 1080p@60Hz

• 🌐 Ethernet: Gigabit RJ45 (10/100/1000 Mbps)

• 💾 Card reader: SD + TF (microSD), up to 104 MB/s (UHS-I / SD 3.0)

• 🧠 OS support: macOS 10.15+; Windows 8/10/11+, Linux: untested - contact seller

• 🌡️ Operating conditions: 0–40°C (32–104°F); 15%–85% RH

• 🧩 Form factor: ultra-slim, low-profile “edge” wedge design

⚙️ Inventory: x0718
