A3-18 UV Printer EPSON 1390 L800 A3/A4 UV Flatbed Printer Machine with 3D Textured Raised Embossed for Glass/Plastic/Leather
Features:
Support up to 5760*1440DPI, more vivid colors Minimum ink drop: 1.5pl, 6X90=540 nozzle holes
White Ink Automatic Circulation White ink circulation to ink sac, prevent the white ink precipitation plug nozzle, general circulation being carried out in the ink bottle, while a white ink will be circulated into ink sac by the circulation system, effectively prevent the white ink precipitation and nozzle blocking
Automatic Height Adjustment When you are printing items, the height is automatically adjusted by infrared rays, and the maximum printing height of the printer is 130mm
Powerful cooling system - through water cooling and air cooling, it supports long-time printing and prolongs the service life
Support Emboss Printing The software's own ink volume control algorithm has a good control over the ink output. When printing pictures with embossed,The color is more vivid and life like, which restores what people see with the naked eye.
Printing White and Color at the Same Time support offerirectional printing, white and color printing at the same time, faster printing
Automatic cleaning using RIP software, press F12 to automatically clean the print head
Specifications： Model：A3-18 (Fully automatic)
Print accuracy：1440 * 1440 dpi
The printing speed：A3 format (about 1440dPI /10min)
Print height：0~120mm, infrared altimetry
Ink consumption：1 square meter /20 milliliters
Ink way：6 colors for ink supply
White ink output：Support/white color together
The UV lamp life：3 years
The UV lamp cooling：Water cooled + air cooled
The UV lamp power：50 ~ 60 w
Platform to adjust：Touch screen + infrared altimetryPrint heads：Epson R1390 l800
The print platform：A3 (297*420mm,UV effective printing area 267*420mm)
software：RIP
Apply to system：WindowXP, 7, 10
Color configuration：CMYK+WW
Relief printing：support
Print the varnish：support
Packing size：Length 770* width 740* height 700mm
The equipment size：Length 660* Width 660* height 500mm
Net/gross weight：50KG/69KG
The outer packing：Export wooden case (with forklift foot) + foam
Voltage/plug：AC100~230V/ Optional according to the country
What is in the box？
UV Printer A3-18
Full Set of Initial UV Ink (CMYKW 5*250ml)
Metal coating 1*50ml
Acrylic coating 1*50ml
Ink cleaner 1*100ml
Nozzle protection fluid 1*50ml
Cylindrical fixture (gift)
RIP software
Other accessories
Printing step
The first step is to design the picture on the computerThe second step is to import the picture into the RIP software and make some simple adjustmentsThe third step is to send a print job to the printerStep 4: Wait for the printing to finish
Printing samples
