Enterprise Multi-Gigabit Layer 3 Switching Ubiquiti UniFi Pro Max 24 PoE (400W) Model: USW-Pro-Max-24-PoE • (8) 2.5 GbE PoE++ • (16) 1 GbE • (2) 10G SFP+ • Etherlighting™ 400W PoE Availability (16) PoE++ Ports (8) 2.5 GbE Multi-Gig Ports (2) 10G SFP+ Uplinks Etherlighting™ Layer 3 Routing USP-RPS DC Backup NDAA Compliant Product Overview
The UniFi Switch Pro Max 24 PoE is a high-performance Layer 3 switch engineered for high-density enterprise access and high-speed Wi-Fi 7 infrastructure. Equipped with 8 auto-sensing 2.5 GbE PoE++ ports, 16 Gigabit RJ45 ports (8 PoE+, 8 PoE++), and dual 10G SFP+ uplink ports, it delivers a massive 400W total PoE budget. Features integrated Etherlighting™ port illumination for immediate visual port location, speed, and VLAN status, dynamic Layer 3 routing, and seamless centralized management through the UniFi Network Controller.
What is Included • 1× Ubiquiti USW-Pro-Max-24-PoE Switch • 1× Set of Rackmount Ears & Mounting Hardware • 1× Standard AC Power Cord Please note: Photos shown are representative/sample images for illustration and do not depict the exact individual unit or serial number received. Shipping & Transit Verification Packaging: Securely packaged and cushioned inside a heavy-duty plain brown shipping carton. Carrier: Tracked, insured standard carrier transit. Protection: Fully tested and packaged to prevent chassis flexing and port damage during transit. Hardware & System Specifications Port Layout • (16) 1 GbE RJ45 Ports (8 PoE+, 8 PoE++)
• (8) 2.5 GbE RJ45 Multi-Gigabit Ports (All PoE++)
• (2) 10G SFP+ Uplink Ports Total Available PoE Budget 400W Total PoE Availability Max PoE Output per Port PoE: 15.4W • PoE+: 32W • PoE++: 60W Switching Capacity 112 Gbps Non-Blocking Throughput 56 Gbps Forwarding Rate 83 Mpps Display 1.3" Touchscreen Status LCM Power Supply Internal 550W AC/DC Power Supply (100–240V AC, 50/60 Hz) Power Redundancy (1) USP-RPS DC Input for Seamless Power Failover Power Consumption 50W (Excluding PoE Output) / 450W (Max with Full PoE Load) Dimensions & Weight 442 × 325 × 44 mm (17.4 × 12.8 × 1.7 in) — 1U Standard Rackmount • 5.1 kg (11.3 lbs) Enclosure & Compliance SGCC Galvanized Steel Enclosure • NDAA Compliant Layer 2, Layer 3 & Management Features Etherlighting™ Technology Port locator illumination, link speed status, and native VLAN color-coding across RJ45 and SFP+ ports Layer 3 Routing Inter-VLAN Routing, Static Routing, DHCP Server (Local Networks), DHCP Relay Link Aggregation & Spanning Tree LACP Port Aggregation, STP, RSTP, Loop Protection, Jumbo Frames Pro AV & Multicast Protocols IGMP Snooping, Querier, Fast Leave, Router Port, Pro AV Profiles (Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) Security & Traffic Isolation 802.1X Access Control, MAC & IP-Based ACLs, Port & Device Isolation, DHCP Snooping & Guarding, Storm Control Hardware Capacities 16,000 MAC Address Entries, 1,000 VLANs, 256 IPv4 Static Routes, 1.5 MB Packet Buffer Authentic Ubiquiti Enterprise Hardware • Fully Tested & Protected for Transit
