Dimensions
235 x 43 x 204 mm
(9.3 x 1.7 x 8")
Port Layout
1 GbE RJ45
8 (All PoE+)
(1G/100M/10M)
1G SFP
2
(1G)
Max. PoE Output
Up to PoE+
Total PoE Availability
130W
Form Factor
Compact desktop, wall
Performance
Switching Capacity
20 Gbps
Total Non-Blocking Throughput
10 Gbps
Supported VLANs
256
MAC Address Table Size
16,000
Packet Buffer Size
1.5 MB
Access />
Layer 2 Features
LACP Port Aggregation
✓
STP & RSTP
✓
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
✓
IGMP Snooping
✓
802.1X Control
✓
MAC-Based ACLs & Device Isolation
✓
DHCP Snooping & Guarding
✓
Egress Rate Limit
✓
Flow Control
✓
Storm Control
✓
Multicast & Broadcast Rate Limiting
✓
MAC Address Blocking
✓
IP-Based ACLs & Network Isolation
✓
MAC-Based Port Restriction
✓
Port Isolation
✓
Port Mirroring
✓
Jumbo VLAN
✓
Loop Protection
✓
Virtual Network Override
✓
Hardware
PoE Ports
PoE+
8
Power Method
Universal input, 100–240V AC, 50/60 Hz
Power Input Method
AC input
Supported Voltage Range
100–240V Material
SGCC steel
Ambient Operating Temperature
-5 to 45° C (23 to 113° F)
Ambient Operating Humidity
5 to 95% noncondensing
NDAA Compliant
✓
Software
Application Requirements
UniFi Network
Version 6.3.51 and later
