bandwidth, which means can experience greater network flexibility, faster downloads, stronger signal, as well as ultra-low latency, lower power consumption.
【High Rate 1800Mbps】Dual-Band wifi dongle supports speed up to AX1800Mbps, with 1200Mbps on 5GHz band and 600Mbps on 2.4GHz band. With
these upgraded speeds, web surfing, gaming, and streaming online are much more enjoyable without buffering or interruptions.
【Super Fast USB 3.0】Work with USB 3.0 ports to meet the transmission requirements of AX1800 Wi-Fi peak speed. Upgrade current laptops, PCs, or Macbooks
to powerful Wi-Fi 6 throughput and speeds and bring you more stable network connection and higher compatibility. Compatible with full-speed USB 2.0 interface,
USB 1.1. The latest WPA3 Wi-Fi security helps to protect your network from attacks.
【Foldable and Portable】It can be folded and is easy to carry, allows flexible placement in and around the computer and helps your computer create a Wi-Fi hotspot
when you're out and share network with others.
【System Compatibility】The USB WiFi 6 Adapter support for Windows 11/10/7, Standards IEEE 802.11 ax/ac/a/b/g/n ( not recommended for Linux or Mac system)
Easy to use with wide operating system support.① Faster Connections with AX1800 Speed
Wavlink 690X1 lets your PC or laptop take full advantage of the high-speed Wi-Fi created by AX1800 dual band adapter. Enjoy connections 3x faster than wireless
AC with wireless AX technology.
② USB 3.0 for Superior Transfer Speeds
Experience blazing-fast data transfers with USB 3.0 . USB 3.0 transfers data up to 10x faster than USB 2.0. Combined with 802.11ax protocol, USB 3.0 makes Wavlink
690X1 ideal for HD streaming, online gaming, and large file downloads.
③ Ultra-Compact and Portable Design
Foldable Dimentions: (WxHxD):2.7 x 1.2 x 0.48 inch
(75.5 x 30 x 12.2mm)
④ Simple and Flexible Installation
Foldable network card and removable base ensure easy installation.
⑤ WiFi 6 Advanced Technology
Wi-Fi 6 1800Mbps total combined bandwidth, perfect for uninterrupted gaming, web surfing and live-streaming.
⑥ Advanced Security
WPA3 encryption standards keep your wireless connection safe from intruders.
⑦ Using OFDMA Technology
Each frame of data can serve multiple users at one time, greatly reducing frequency attenuation and interference problems, and providing better deterministic WS-WN690X1-A
Weight: 3.7oz(105g)
Product Foldable Size: 2.7 x 1.2 x 0.48 inches(75.5 *30 * 12.2mm)
Operating Temperature: Humidity: wireless speed
•Support 2.4GHz & 5GHz WLAN networks
•Dual Band connections for lag-free HD video streaming and gaming
•SuperSpeed USB 3.0 port, backward compatible to USB 2.0
•Complies with IEEE 802.11ax/ac/a/b/g/n, standards
•20MHz & 40MHz & 80MHz bandwidth transmission
•OFDMA with BPSK, QPSK, 16QAM, 64QAM, 256QAM,1024QAM modulation
• Supports Windows 11/10 /7
Important Notes:
● 1. USB3.0 is compatible with USB2.0, if the product is connected to a USB2.0 interface, the maximum network speed is 480Mbps
● 2. Only supports Windows 7/10/11, not for Mac, Linux, Chrome and other systems
PACKAGE CONTENT:
1 x Wireless-AX USB3.0 Aapter
1 x USB3.0 DOCK
1 x Quick Installation
1 x Driver link card Wi-Fi 6E AX5400 Tri-band USB3.0 WiFi Adapter--Soaring to New Height!
The AX5400 WiFi 6E adapter revolutionizes your PC's wireless capabilities with record-breaking speeds of up to 5G:2402Mbps, 6G:2402Mbps, and 2.4G:573Mbps.
This impressive speed ensures rapid data transfers, smooth streaming, and lag-free gaming experiences. With advanced technologies like OFDMA and MU-MIMO,
this adapter enhances network efficiency even in busy environments with numerous connected devices. It optimizes bandwidth allocation and enables multiple
devices to communicate simultaneously, resulting in improved overall network performance.
⭐Upgrade WiFi 6E Standard: This WiFi 6E adapter is designed to provide enhanced capacity and improved performance for your wireless connectivity needs.
It supports the latest 802.11ax technology, which includes advanced features like OFDMA, MU-MIMO, and 1024QAM. These technologies work together to
optimize data transmission, allowing for higher speeds and more efficient use of the available bandwidth.
⭐Tri-band Speeds: The advanced Realtek chipset extends WiFi to the 6GHz band, enabling speeds up to 573Mbps on 2.4GHz, 2402Mbps on 5GHz, and another
2402Mbps on 6GHz. The 2.4GHz band is for long-range transmission, 5GHz is ideal for gaming and 4K streaming, while 6GHz ensures smooth gaming and
immersive VR.
⭐Flexible Usage: The WiFi adapter comes with a 1 meter USB 3.0 cable, providing flexibility in positioning the device for optimal signal reception. With USB 3.0
technology, you can experience blazing-fast transfer speeds. USB 3.0 offers data transfer rates up to 10 times faster than USB 2.0, allowing for quick and efficient
transmission of data between your device and the adapter.
⭐Broader WiFi Coverage: The WiFi card is equipped with four high-gain 5dBi rotatable antennas, providing enhanced signal strength and improved coverage.
With their increased gain, these antennas can effectively penetrate walls and other obstacles, minimizing dead zones and ensuring a stable connection in every corner of your space.
⭐Universal Compatiblity: This USB 3.0 WiFi 6E wireless adapter is fully compatible with Windows 10/11 operating systems. It seamlessly works with any WiFi
6E or WiFi 6 router or mesh system, ensuring a reliable and high-speed connection. This network adapter features built-in drivers, eliminating the need for manual
driver Realtek Chip
Providing you with consistent and reliable connectivity, ensuring a strong and reliable WiFi signal throughout your home or office.
High Gain Quad Antennas
Brings much stronger WiFi connection than other WiFi adapters with only one or two external antennas.
Widely Compatible
Support Windows 10/11 based desktop/laptop, not for M1/M2/M3 based MacBook.
USB 3.0 Transmission
Plug into your PC via its slim USB cable, with no adjacent USB port blocked. Also works with USB2.0.
Advanced Wi-Fi Security
Support WPA2-PSK/WPA3-PSK data encryption to improve network security, protect your privacy.
Minimized Lag on Busy Network
MU-MIMO improves the throughput and efficiency of your entire network when using a compatible MU-MIMO router.
Connect More, Congest Less
Compared with WiFi 5, this WiFi 6E adapter can supply higher data capacity and higher data transfer speed.
Receive & Launch WiFi
This USB wireless adapter supports station mode and soft AP mode. In soft AP mode, you can convert your wired computer into a WiFi hotspot for other Model: WN695X2
Transmission Rate: 2.4GHz: 573Mbps, 5GHz: 2402Mbps, 6GHz: 2402Mbps
Protocol Standard: support IEEE 802.11a/b/g/n/ac/ax
Frequency Band: 2.4GHz, 5GHz, 6GHz
Technical Support: MU-MIMO, OFDMA
Support System: Win 11/10 (64 bit)
Interface: USB3.0
Size: Length: 18cm/7in
Wireless Security: WPA2/WPA3, WPA2-PSK encryption
USB Cable Length: 1m/3.28ft
Package Contents
-1x AX5400 Tri-band Wireless Adapter
-1x USB3.0 Cable
-1x User Manual
