Zdock is a Dual video USB Docking Station that integrates into the base of any Zgo monitor arm. It offers numerous benefits to your workstation, as detailed below: (Monitor Arm sold separately)
Eliminates Desktop Cable Clutter and Increases Usable Workspace
The combination of a monitor arm, with full cable management, and a dock at its base, allows all cables to be routed through the arm to the rear of the dock where the video cables are connected and power drops behind the desk to outlets.
This eliminates virtually all cables from the desktop, which increases usable workspace the cleanliness, neatness and orderliness of the work environment.
Usb-C full feature with 100W PD charging
Support PD2.0 version 1.2
2x Usb-A 3.1 Gen1 (5V,0.9A max)
Usb-C (5V, 3.0A max)
Usb-A (5V, 2.4A max)
TRRS 3.5mm combo jack for Apple/Samsung type
2 x DP++ (Dual mode DP1.2)
Support:
5k - 5120x2880p60 (Only 1 video connection)
4k - 3840x2160p60, 4096x2160p60
2k - 2560x1600p60, 2560x1440p60
1k - 1920x1080p60
Gigabit Ethernet
Transfer rate 10Mbit/100Mbit/1Gbit
3x Usb-A 3.1Gen1 (5V, 0.9A)
Windows 7/7Pro (32bit/64bit),
Windows 8.1/8.1Pro (32bit/64bit),
Windows 10 (32bit/64bit),
Apple OS X Version 10.8.3 and above
(Mountain Lion v10.8, Mavericks v10.9, Yosemite v10.10, El Capitan v10.11(ver2.5), Sierra mac OS10.12(ver2.6) )
Operating: 0°C to 40°C
Non Operating: -20°C to 60°C
Operating: 10% to 80% (non-condensing 5 to 35oC) Non Operating: 5% to 90% (non-condensing -20 to 60oC)
Operating: Sea level to 5000m
Non Operating: 5000m
Designed to meet RoHS and WEEE directives
2kg box packed
Input Voltage: 90 – 264V (47-63Hz)
Output Voltage: 20V (+/- 5%), 7.5A, 150W Efficiency: Meets US DoE VI
Mainscord: Mickey mouse(IEC60320-C5), 1.8m
1x USB-C full feature cable,
1.0m with USB-C to USB-A adapter
