【Comprehensive Cooling System】Constructed with a robust aluminum alloy case, this SSD enclosure ensures optimal protection for your SSD while prioritizing efficient heat dissipation. The inclusion of two thermal silicone pads facilitates dual heat ventilation effects. With its sandwich-like cooling system, this enclosure effectively safeguards your SSD against overheating, ensuring stable and smooth data transfers.

【Extensive Compatibility】Designed to accommodate M key and B&M Key PCIe NVMe SSDs, this enclosure supports double-side SSDs in sizes of 2280, 2260, 2242, and 2230 (SSDs not included). It is also compatible with various operating systems, including Windows 7 or later, Mac OS 10.5 or later, and Linux, enabling seamless data transfer across different devices. Please note that the enclosure does not support AHCI SATA SSDs.

【Plug and Play & Tool-Free】With its compact dimensions of 11.6 x 5.2 x 2cm and lightweight design of 150g, this portable enclosure can easily fit into a pocket or briefcase, granting you access to extensive storage capacity anytime and anywhere. It supports plug and play, allowing for a direct connection with devices without additional drivers. Furthermore, the tool-free installation feature enables you to install the SSD without extra tools, providing convenient external storage for on-the-go use.

【Intelligent Chip & Multiple Protection】The advanced ASM2464PD chip ensures safe and smooth operation of the enclosure while effectively reducing SSD-generated heat. It also supports UASP and Trim, which minimize data delay and speed loss, significantly enhancing the transmission speed. Additionally, the enclosure supports S.M.A.R.T., simplifying SSD status monitoring, conserving energy, and extending the service life of your SSD.

Better Heat Dissipation
The heat generated by the SSD during operation will lead to transmission interruption and damage to the SSD if not discharged in time. WAVLINK ST401C addresses this concern by incorporating dual thermal silicone pads and an aluminum alloy case, ensuring effective heat dissipation from the inside out.

Widely Compatible
Designed to work with laptops running Windows 7 or later, Mac OS 10.5 or later, and Linux. Please note: The performance might be limited on Thunderbolt 3 and normal USB-C port. To get the advertised performance, the host should support Thunderbolt 4 or USB 4 and it should support the data transfer speed of 40Gbps.

Suitable for Most SSDs
The enclosure supports both one-side SSDs and double-side SSDs in sizes of 2280, 2260, 2242, and 2230. The SSD should have an M-key or M&B-key connector and support PCIe and NVMe protocols. Please note that this enclosure does not support AHCI SATA SSDs or SSDs with a B-key connector.

How to Install the SSD?
Step 1: Push the cover in the direction of the arrow to open the top lid of the enclosure.
Step 2: Before installing the SSD, stick the two thermal silicone pads to both sides of the SSD respectively.
Step 3: Insert the SSD and use the silicone buckle to fix it.
Step 4: Reassemble the top lid and complete the installation.

Travel-Friendly Design
The pocket-size enclosure measures only 11.6 x 5.2 x 2 cm and weighs 150g, ideal for carrying it to school, the office or on business trips. The tool-free installation adds additional convenience to your on-the-go use. The enclosure also supports plug and play, just connect it with your USB-C laptop to experience ultra-fast data transmission without installing any drivers.

Applicable to Multiple Scenarios
Featuring a 40Gbps USB4 port and an effective heat dissipation system, the SSD enclosure ensures swift and stable data transmission of large files, such as XBOX/Switch games, extensive education software, media files, and personal data backups, making the enclosure particularly well-suited for students, IT enthusiasts, photographers, etc.

Unleash the Power of a 8TB SSD
Experience the ultimate storage solution with support for a massive 8TB SSD. Expand your storage capabilities without limits and say goodbye to worries about running out of space. Upgrade your laptop to a high-capacity storage platform and enjoy the freedom and convenience it brings!

Compatibility Notes
Systems: Windows 7 or higher, Mac OS 10.5 or higher, Linux;
Host: Computers with a USB-C port;(The performance might be limited on TBT3 and normal usb port. To get the advertised performance, the host should support TBT4 or USB4 and it should support 40Gbps.)
SSD: Support M key and B&M Key PCIe NVMe SSDs(both one-side and double-side) in sizes of 2280, 2260, 2242, and 2230; NOT support B Key SSDs and AHCI SATA SSDs.

Specification:
1.Model: WL-ST401C
2.Unit Size: 11.6 x 5.2 x 2 cm/ 4.6 x 2 x 0.8 in (WxDxH)
3.Cable Length: 25cm/9.8in
4.Unit Weight: 150g/5.3oz
5.Housing Material: Aluminum Alloy
6.LED Light: Blue

In the Box
-1×USB4 PCle NVMe SSD Enclosure
-1×USB-C to USB-C Cable (40Gbps)
-1×Silicone Buckle
-1×Silicone Case
-1×Pouch
-2×Thermal Silicone Pad
-1×Quick Start Guide
(Note: the NVMe SSD is not included)

Warm Tips:
1.The NVMe SSD is not included.
2.The performance might be limited on TBT3 and normal usb port. To get the advertised performance, the host should support TBT4 or USB4 and it should support 40Gbps.
3.This test result for Max.3800MB/s reading and Max.3800MB/s writing is the best result tested by our own test environment, and the specific effect is determined by the computer configuration and your SSD.
4.If the SSD is brand-new and unformatted, please perform partition installation so that the computer can read the data normally. If the SSD is formatted and has stored data, you have no need to perform partition installation because the computer can read the data normally.

40 Gbps-Thunderbolt 3 to NVMe

This gadget turns your NVMe SSD into an external storage solution. It works over Thunderbolt 3 host interface
at up to 40 Gbps bus bandwidth, so you can take full advantage of the latest PCIe 3.0 x4 NVMe SSDs.
Integrated heatsink works together with aluminum casing and side vents to efficiently dissipate heat and prevent throttling.
The included Thunderbolt 3 cable has an anchoring clip for secure connection to the enclosure's Thunderbolt port. Plus,
leather-like covering on the enclosure casing gives enhanced comfort and control when this enclosure is held in hand.

• ⭐ High-Speed Thunderbolt 3 Technology: Boasting a super-speed rate of 40Gbps, this portable drive is among the fastest in the market, offering transfer rates six to seven times faster than SATA drives. The maximum continuous read speed is measured at 2,500MB/s, with a continuous write speed of 2,000MB/s and a theoretical maximum speed of 3,940 MB/s. Trim/S.M.A.R.T is supported for steady and speedy transmission. (Note: Speed may vary in different environments, as per Wavlink laboratory data.)
• ⭐ Exclusive Compatibility with NVMe PCIe M.2 SSDs: Tailored for M-Key & B+M Key NVMe PCIe SSDs up to 4TB and applicable to size 2280 solid-state drives. This Thunderbolt 3 M.2 SSD Enclosure facilitates easy connections for file backup, disk upgrades, cloning, data recovery, and storage expansion. It supports only single-sided SSDs and does not support NGFF SATA-based B-Key and M&B-Key M.2 SSDs, M.2 PCIe AHCI SSDs, mSATA SSDs, or B Key NVMe. (Not recommended for Samsung Plus version SSDs.)
• ⭐ Windows & Mac Compatibility: Designed exclusively for Mac and Windows PCs equipped with Thunderbolt 3 ports. Not compatible with standard USB-C ports, Thunderbolt 1 or 2. Supported on Windows 10, 8.X, or 7 (Boot Camp with Windows 10 version 1809 and up) and Mac OS 10.X or later. Also compatible with the latest version of the Apple tablet "iPad Pro 2021."
• ⭐ Exceptional Self-Cooling Structure: Featuring an enhanced heat dissipation design with an integrated heat sink, providing optimal ventilation for high-speed NVMe SSD operation. The surface offers improved heat dissipation, ensuring the inner chip stays cool and safe. Note: NVMe SSDs may generate significant heat during continuous operation; caution is advised when handling.
• ⭐ Thunderbolt 3 - Your Ultimate Choice: With speeds up to 40Gbps, Thunderbolt 3 stands out as the most advanced and fastest interface available. The USB-C port supports reverse insertion. Backed by advanced performance, this product can transfer a 4K movie within seconds. It is popular among Thunderbolt 3 system users, Macbook enthusiasts, and serves as an excellent solution for gamers looking to load and boost games rapidly.

This SSD is plug and play, you can easily use it with your laptops to read and write data, no need of other driver or installation.

Only compatible with NVMe SSD thickness below 2.5mm, socket low profile design for single sided NVME SSD only,
if the thickness of SSD is more than 2.5mm, the heat sink will protrude during the installation process, resulting in damage to the SSD.

• High Performance PCs and Laptops
• Gaming
• Ultra HD or 4K Video Creation
• VR Content Creation
• High-Bandwidth Corporate Computing

Due to its delicate and portable design, you can easily take it wherever you go, just slip it into your pocket or briefcase, save more space for you. Simple pure design Fits in your hand, this SSD is definitely your perfect partner for your work.

Thunderbolt 3 supports 4x PCIe 3.0 lane, help you transfer photos, videos, data, all in the blink of an eye.( actual drive speed may vary due to media and file system overhead, and potentially thermal throttling for some SSDs)

Enclosed by aluminum alloy, this SSD is dust-proof and wear-resist. Heat sink integrated giving better ventilation for NVMe SSD running at high speed. Files are more secured.

High-speed Thunderbolt 3 NVMe m Key m.2 SSD enclosure, support PCI-E×4, theoretical transmission speed up to
40Gb/s (MAX).Not all Thunderbolt 3 computers are x4 full speed, part of which maybe x2.

• Hardware accelerated architecture enables very low latency and low power
• Scalable NVMe architecture enables an efficient qualification process and maintains significantly higher performance over SATA
• Heat sink integrated giving the best ventilation for NVMe SSD running at high speed.
• Plug and play. No need for external power.

• NVMe SSD thickness below 2.5mm.
• Socket low profile design for single sided NVME SSD only.

Due to the variety of computers used by customers, the computers used by customers may not have a Thunderbolt 3 port.
This product is only suitable for computers with Thunderbolt 3 port, not for ordinary USB C ports. Compatible for MacBook
Pro 2016+/MacBook Air 2018+ and Thunderbolt 3 Laptops PC.

This SSD is plug and play, you can easily use it with your laptops to read and write data, no need of other driver or installation.

• Not compatible with: M.2 SATA SSDs, M.2 PCIe AHCI SSDs, or other M.2 non-NVMe devices.

Scalable NVMe architecture, the NVMe SSD enclosure is breaking through performance limits of client computing,
enabling partners to support higher storage applications in today’s mobile and ultra-thin computing markets.

This product only supports Type C interface computers with Thunderbolt 3 protocol,and doesn't support ordinary Type C
interface computers without Thunderbolt 3 protocol. Please confirm whether the computer Type c interface has Thunderbolt 3 logo.

• 1x Thunderbolt 3 NVMe External SSD enclosure
• 1x Thunderbolt 3 protocol special high-speed data cable 50cm (Intel Certified)
• 1x Heat Sink
• Installation Tool
• 1 x Protect Pouch
• 1 x Quick Start Guide

Main Features
•Plug & Play and Hot-Swapping. Easy installation & no driver required. No additional power required.
•Support all 2230 2242 2260 2280 PCIe NVMe M.2 SSD of M-Key or M+B Key.
•UASP supported, USB-C Gen 2 or Thunderbolt 3 hosts up to 10Gbps, USB-C Gen 1 and USB 3.0 systems capable of up to 5Gbps.
•Aluminum alloy case with ventilation holes, which is better for heat dissipation, no worry about over-heat.
•Built with short-circuit, over-current and multi-protection to ensure safety for your SSD and valuable data.

Warm Reminder:
1. Your computer won't recognize the actual SSD's brand with this NVME to USB Adapter, so for Samsung SSD that you couldn't use the Samsung disk cloning software
2. For the brand new SSD drive, it may not find the drive, because the brand new SSD drive should be formatted before first time using. And also need to make the SSD drive partition.

10Gbp Super Speed & UASP Supported
This M.2 SSD enclosure features the latest USB 3.1 Gen 2 and PCIe GEN 3, which supports amazing data transmission rate up to 10Gbp. You can transfer 1GB files in 1 second.
The USB 3.1 interface incorporates with UASP (USB Attached SCSI Protocol) that enables it to perform a 70% faster read speed and 40% faster write speed than conventional USB 3.1 when used with a UASP-enabled host computer.

Designed for NVMe PCIe M.2 SSD
The NVMe M.2 Enclosure is specially designed for M-Key and M+B Key PCIe NVMe M.2 SSD of 2230/2242/2260/2280 and up to 2TB, Does not support NGFF SATA based B-Key and M&B-Key M.2 SSD, M.2 PCIe AHCI SSD, mSATA SSD.

Excellent Heat Dissipation
Made of premium aluminum case with ventilation holes that does better at heat dissipation, no need to worry about overheat.

OTG functionality, Super Convenience
Back up pictures and watch movies at anytime and anywhere.

Inteligent LED Indicator
With blue LED indicator, you can learn of the working status of this M2 Case easily.

Compact and Durable
Wavlink M.2 NVMe enclosure with a dimension of 0.39x1.14x4.33 in, the case is compact and lightweight to take for daily working needs. The silicone case provides an extra protection, making it robust and durable, no need to worry about accidental falling and crashing.

Universal Compatiblity
Compatible with Windows, Mac OS, Linux, Chrome OS, PS4, PS3, Xbox, router, OTG Phones. Enable your M.2 SSD to be a mobile database between your devices.
