40KM Drone TTL Fiber Optic Transceiver Module Air & Ground for UAV FPV

AP Management: 1
Product Type: Fiber Optic Transceiver
WAN Access Points: 1
Mounting Method: Direct Mount
Model: Sky End A + Ground End B
Package Type: SOP-2
Video Interface: BNC or Pin Pin
Video Input/Output Impedance: 75Ω (Unbalanced)
Video Bandwidth: 8MHz
Video Compatible Formats: PAL, NTSC, SECAM
Video Voltage: 1VP-P
Video Signal-to-Noise Ratio: 70dB
Applicable Cameras: Analog Cameras, CVBS Cameras
Serial Port Type: UART
Baud Rate: 115.2Kbps
Fiber Optic Interface: FC Standard Optical Module 1*9
Transmission Distance: 40KM
Product Weight: 14.5g


1.Long-distance, zero-attenuation transmission: Supports transmission up to 60km (100km optional), with no signal attenuation, real-time low latency, suitable for FPV drones and long-distance inspection, stable and lag-free.
2.Strong anti-interference: Dual-wavelength fiber optic technology, unaffected by electromagnetic interference, stable transmission in deep-sea/high-temperature/high-pressure scenarios, suitable for underwater/exploration robots.
3.Plug and play: Driver-free plug and play, rapid deployment; ultra-lightweight design of only 14.5g, low load, high efficiency and energy saving, extended battery life.
4.Wide compatibility: Compatible with PAL/NTSC/SECAM formats, adaptable to analog/CVBS cameras and UART serial ports, covering multiple industries such as power, surveying, and plant protection.
5.Industrial grade: Uses high-quality chips and FC standard optical modules, 70dB high signal-to-noise ratio, strict quality control, reliable performance guaranteed.

100% brand new and high quality.
Shape and Color: Same as shown in the picture

Type is your choice!!
Quantity is your choice!!
Thank you for your patronage and wish you a pleasant cooperation!!
Note: Due to the characteristics of the product and the measuring tools, plus the pure manual measurement and cutting of the cable, the length may have an error of 1%-5%.
