NEoeco

gold modular 850W

850W Continuous Power™ - Guaranteed 850W of Continuous Powerfrom Antec

100% Modular - Improves airflow and reduces clutter

80 PLUS® Gold certified -Reduce your electricity bill

PhaseWave™ Design - A server-class LLC design with asynchronous rectification based on a DC-DC topology

Antec Quality 7-year warranty

120mm Silent Fan - Whisper-quiet high-quality fluid-dynamicbearing fan with long life time

Zero RPM Manager - An advanced low voltage fan control withfan-off mode at low loads for absolute silence

99%+12V - Output for maximum CPU & GPU support

High-Quality JP capacitors achieve unprecedented tightvoltage regulation & low ripple & noise to maximize your system’sperformance

28(18+10) pin MBU socket - For possible future MBUconnectors

ATX 12V 2.4－Engineered according to the newest PSU guideline andcompatible with the latest CPU generation

SPECIFICATIONS

Model NE850G M

Type ATX 12V 2.4

Modular Fully

Dimension 150(L)x 140(W) x 86(H)

Warranty 7years

Input Voltage 100-240VAC

Input Current 10AMAX

Input Frequency Range 50Hz-60Hz

PFC Active PFC

Power Good Signal 100-500ms

Efficiency UpTo 92%

Protection OCP/ OVP / UVP / SCP / OPP / OTP / SIP / NLO

Output Capacity 850W

Operation Temperature 0~40°C

Regulatory cTUVus/ TUV / CB / RCM / CE / CCC / FCC / KC

Fan 120mmSilence Fan

Certifications 80Plus Gold

Connector 1 xMB 24(20+4) Pin

2 x 8(4+4) Pin EPS 12V

6 x 8(6+2) Pin PCI-E

10 x SATA

5 x Molex

1 x FDD

Net Weight 1.38kgs

Gross Weight 2.55kgs
