Motherboard chip
Integrated chip
Sound/network card
Main chipset
Intel X299
Chipset description
Powered by Intel X299 chipset
Display chip
CPU built-in display chip (requires CPU support)
Audio chip
Integrated ROG SupremeFX 8-channel audio chip
Network card chip
Onboard Intel I219V Gigabit network card
Processor specifications
CPU type
Core X-series
CPU socket
LGA 2066
Memory specifications
Memory type
8×DDR4 DIMM
Maximum memory capacity
128GB
Memory description
Supports dual-channel DDR4 4133 memory
Storage expansion
PCI-E standard
PCI-E 3.0
PCI-E slots
3× PCI-E X16 graphics card slots, 1× PCI-E X4 slots, 2× PCI-E X1 slots
Storage interfaces
1× M.2 interface,6×SATA III interface
I/O interface
USB interface
2× USB3.1 Type-A interface, 8×USB3.1 Gen1 interface (4 built-in +4 backplane), 6× USB2.0 interface (2 built-in +4 backplane)
Power connector
One 4-pin, one 8-pin, one 24-pin power connector
Other interfaces
1× RJ45 network interface, 5× audio interface, 2× chassis fan interface, 1×M.2_ fan interface, 1× CPU optional fan interface, 1× temperature sensor interface, 1 ×AIO_ water pump interface, 1 ×W_PUMP+ interface, 1× 3D mounting screw interface, 1× optical fiber interface, 1×PS/2 keyboard and mouse universal interface
Form factor
Motherboard form factor
ATX form factor
Form factor
30.5×24.4cm
Software management
BIOS performance
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM2.0, SM BIOS 3.0, ACPI 6.0, Multi-Chinese BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 Favorites, History, F12 Screenshots,
Memory SPD Information
Other parameters
Multi-graphics technology
Support for NVIDIA Quad-GPU SLI technology Support for NVIDIA 3-Way SLI technology Support for AMD Quad-GPU CrossFireX technology Support for NVIDIA SLI two-way crossfire technology
Support for AMD 3-Way CrossFireX technology
RAID function
Supports RAID 0, 1, 5, 10
Listing date
