GeneralActive PFC CompatibleYesEnergy SavingGreenPower UPS™ Bypass TechnologyEnergy Star CertifiedYesUPS TopologyLine InteractiveBatteryBattery Quantity4Battery Size12 V / 7 AhBattery TypeSealed Lead-Acid BatteryExtended Battery ModuleBP48VP2U01Hot SwappableYesReplacement Battery CartridgeRB1270X4HReplacement Battery Cartridge Quantity1Runtime at Full Load8 minRuntime at Half Load20 minTypical Recharge Time3 Hours (0% to 90% charged)User Replaceable BatteryYesInputAdjustable Voltage Range70 – 155 VACCircuit Breaker15 ACord Length10 ft (3.0 m)Input Frequency Range47 Hz – 63 HzInput Plug TypeNEMA 5-15PInput Voltage100 – 125 VACInput Voltage Range75 VAC – 149 VACNominal Input Voltage120 VACPlug StyleRight Angle – 45° OffsetOutputAutomatic Voltage RegulationDouble Boost
Single BuckOn AC WaveFormSine WaveOn Battery Frequency50/60 Hz ± 1%On Battery Voltage100/110/120/125 VAC ± 5%On Battery WaveformSine WaveOutlet Type8 – NEMA 5-15ROutlets – Battery & Surge Protected8Outlets – Critical Load4Outlets – Total8Output Power Factor1Overload ProtectionInternal Circuitry Limiting
Circuit Breaker ProtectedTypical Transfer Time6ms; Max 11ms at normal sensitivityUSB Charge PortNoVA1000 VAWatts1000 WSurge Protection & FilteringEMI/RFI FiltrationYesSurge Suppression (Joules)2430 JManagement & CommunicationsAudible AlarmsBattery Mode
Low Battery
Overload
Overcharge
OverheatEmergency Power Off (EPO) PortYesHID Compliant USB PortYesLCDMultifunction LCDLED IndicatorsPower On
Line Mode
Battery Mode
Fault
Night Mode
Wiring FaultManagement CableUSB Cable
Serial Cable
EPO CableSNMP / HTTP Remote MonitoringYes – with optional RMCARD205
Yes – with built-in RJ45 ethernet connection cloud portSerial Port1 Serial
1 Dry ContactSoftware (Free Download)PowerPanel® BusinessPhysicalColorBlackForm FactorRack / TowerMaterial of ConstructionMetalRack Height2UDimensionsPhysical Dimensions – (WxHxD) (cm)43.43 x 8.64 x 41.15 (cm)Physical Dimensions – (WxHxD) (in)17.1 x 3.4 x 16.2 (in)Physical Dimensions – (WxHxD) (mm)434 x 86 x 411 (mm)Physical Weight (kg)25.08Physical Weight (lb)55.3Dimensions – ShippingShipping – Weight (kg)27.76Shipping – Weight (lb)61.2Shipping Dimensions – (WxHxD) (cm)52.71 x 27.31 x 55.88 (cm)Shipping Dimensions – (WxHxD) (in)20.75 x 10.75 x 22 (in)Shipping Dimensions – (WxHxD) (mm)527.05 x 273.05 x 558.8 (mm)EnvironmentalOnline Thermal Dissipation48.6 BTU/hrOperating Elevation0 – 9843 ft (0 – 3000 m)Operating Relative Humidity0 – 95 % (non-condensing)Operating Temperature32 – 104 °F (0 – 40 °C)Storage Elevation0 – 49213 ft (0 – 14999 m)Storage Temperature5 – 113 °F (-15 – 45 °C)CertificationsEnvironmentalRoHS CompliantSafetyUL1778
CSA C22.2 No 107.3
FCC Class B
VCCI
DOE CompliantWarrantyCEG Amount$400000Connected Equipment GuaranteeLifetimeExtended Warranty OptionWEXT5YR-U4AProduct Warranty3 Year Limited Warranty
