WAVLINK · UNIVERSAL DOCK · 13-IN-1 · DisplayLinkUSB-C Dual DP 5K Universal Docking StationDual 5K / 4K@60Hz · 100W PD · Gigabit Ethernet · 10Gbps USB-COne dock for all devices. Dual HDMI & DisplayPort outputs, 6 USB ports, wired Gigabit Ethernet and audio in a single USB-C connection — with a USB-A adapter for legacy laptops.🖥 Dual 5K / 4K🔋 100W PD⚡ USB-C 10Gbps🌐 Gigabit LAN🎧 Audio & Mic13-in-1Connection Ports5K@60Hzvia DisplayPort4K@60Hzvia HDMI100WUpstream PD10GbpsUSB-C TransferFeaturesOne Dock for All DevicesDual 5K resolution, 100W charging, six high-speed USB ports and wired networking — all from a single USB-C cable.🔌13-in-1 DockingA single USB-C connection from a host PC to this dock provides dual HDMI & DisplayPort outputs, wired Gigabit Ethernet, a 3.5mm headphone and microphone jack, 4 × USB-A 5Gbps, 2 × USB-C 10Gbps ports. Security lock is supported. One dock for all devices.🖥Dual DP 5K DisplaySupports both dual and single display configurations with resolutions up to HDMI 4K (4096×2160) or DP 5K (5120×1440) at 60Hz. Perfect for HD multitasking, conference or general work scenarios. May not be suitable for image-intensive tasks.🔋Max 100W Power DeliveryThe Type-C upstream port passes up to 100W to your host PC (host must support charging) while the included 130W power adapter supplies extra power to hard drives, peripherals and accessories connected to the USB ports. One USB 5Gbps port provides 7.5W phone charging.⚡Fast & Stable ConnectionInstant stable internet with the 1000M Ethernet port — grab a 1GB movie in minutes. The six multifunctional USB-A/C ports feature ultra-fast data transfer at 5 / 10Gbps. A 2-in-1 audio port provides crystal-clear sound.🌐Universal CompatibilityWith a USB-C to USB-C cable and USB-A converter, it is compatible with most Mac and Windows laptops that feature Type-C and USB-A ports. Supported systems: Windows 11 / 10, MacOS 11.x or later, Android, Chrome OS and Ubuntu. (Go to the DisplayLink website for more information.)Port Layout13 Ports at Your FingertipsEverything expands from one USB-C host connection.Video Outputs 2 × DisplayPort (up to 5K@60Hz)
2 × HDMI (up to 4K@60Hz)Data Ports 2 × USB-C 10Gbps
4 × USB-A 5Gbps (one 7.5W charging)Network & Power 1 × RJ45 Gigabit Ethernet (10/100/1000Mbps)
1 × USB-C Upstream (100W PD)
1 × DC IN (20V/6.5A, 130W)Audio & Security 1 × 3.5mm TRRS 4-pole Phone Jack
Headphone + Microphone 2-in-1
1 × Security Lock Slot Display ResolutionSingle & Dual Display ModesExtend or mirror on both Windows and macOS. DisplayLink chipset ensures stable output.① Single DisplayPortMax ResolutionHDMI4K (4096 × 2160) @60HzDisplayPort5K (5120 × 1440) @60Hz② Dual DisplayCombinationMax ResolutionDual HDMI2 × 4K (4096 × 2160) @60HzDual DisplayPort2 × 5K (5120 × 1440) @60HzHDMI + DisplayPort4K (4096 × 2160) @60Hz⚠ Important: There are two ports in each section (Display 1 & Display 2) that support one monitor at a time. Please choose the type of port you need — do not connect both the DP and HDMI of the same section simultaneously. SpecificationTechnical DetailsVideo Outputs 2 × DisplayPort (up to 5120×1440@60Hz)
2 × HDMI (up to 4096×2160@60Hz)
Support dual display mirror or extendUSB Ports 2 × USB-C 10Gbps
4 × USB-A 5Gbps (one supports 7.5W charging)Power DeliveryUp to 100W upstream charging for laptopEthernet1 × Gigabit LAN (backward compatible with 10/100Mbps)Audio1 × Integrated TRRS 4-pole Phone Jack (audio in & out)SecurityKensington security lock slot supportedPower AdapterDC 20V/6.5A, 130W (included)CompatibilitySupported Systems & DevicesPlease check the list below before purchasing. If your device is not listed, contact us and we’ll be glad to help verify compatibility.✅ Supported Operating Systems Windows 11 · Windows 10 · MacOS 11.x or later · Android · Chrome OS · Ubuntu USB-C / USB-A Host Compatible Devices (Partial List)BrandSeries / ModelsAppleMacBook Air · MacBook Pro · iMac · Mac miniDellXPS · Latitude · Inspiron · Vostro · Alienware · G series · Precision · Latitude Rugged · Dell ChromebookAsusProArt Studiobook · Zenbook · Vivobook · Chromebook · ExpertBook · ROG Zephyrus · ASUS Laptop · BR series · TUF Gaming · ROG Flow · ROG StrixMSITitan GT · Stealth · Raider GE · Vector GP · Crosshair / Pulse · Sword / Katana · Cyborg / Thin GF · Delta · Alpha · BravoAcerSwift · Aspire · Spin · Nitro · Enduro Urban · TravelMateHPHP Chromebook · HP Laptops · Pavilion · Envy · Dragonfly Pro · Spectre · OMEN · VictusLenovoThinkPad · ThinkBook · Yoga · Legion · LOQ · IdeaPad · Slim · ChromebookSamsungGalaxy Book · Galaxy ChromebookRazerRazer Blade seriesMicrosoftSurface Book · Surface Laptop · Surface Pro · Surface Studio 2+ · Surface GoImportant NotesBefore You Buy01Laptops without USB-C ports: you can use the included USB-A to C cable if your laptop doesn’t have any USB-C port. This A-to-C cable is not used for Power Delivery — it only transfers data. Please charge your laptop with its original power adapter.02Dual 4K display grouping: there are two ports in each section (Display 1 & Display 2) that support one monitor at a time. Please choose the type of port you need — either DP or HDMI, not both in the same section.03Host charging support: the upstream Type-C port delivers up to 100W PD, but only if your host laptop’s Type-C port supports charging.04Driver required: the DisplayLink chipset requires driver installation. Please download the latest driver from the DisplayLink website before first use.05Intended use: ideal for office tasks and general productivity. May not be suitable for image-intensive tasks such as professional gaming or GPU-heavy rendering.In the BoxWhat You’ll Receive✓1 × USB-C Dual 5K Universal Docking Station ✓1 × USB-C to USB-C Cable with USB-A Converter (1M) ✓1 × DC 20V/6.5A 130W Power Adapter ✓1 × AC Power Cable (1.5M) ✓1 × Quick Start Guide WAVLINKUSB-C DUAL 5K UNIVERSAL DOCKING STATION · WL-UG69PD2N PRO · 13-IN-1 · 100W PD
