CPU Socket 1567
CPU Support Intel® Nehalem-EX Xeon® Processor 7500 Series up to 130 Watts
Solution 2U&Up Server
Overall Dimension 94.0 x 90.0 x 66.0 mm
Weight 440 ± 5g
Material Copper Base & Aluminum Fins with Heatpipes embedded
Fan Dimension 77 x 77 x 20 mm
Speed At Duty Cycle 0~20%: 1000 RPMAt Duty Cycle 50%: 2600 RPMAt Duty Cycle 100%: 5500 RPM
Bearing 2 Ball Bearing
Rated Voltage 12
Power At Duty Cycle 0~20%: 0.54 WAt Duty Cycle 50%: 1.68 WAt Duty Cycle 100%: 9.0 W
Air Flow At Duty Cycle 0~20%: 8.36 CFMAt Duty Cycle 50%: 25.5 CFMAt Duty Cycle 100%: 53.9 CFM
Noise Level At Duty Cycle 0~20%: 20.6 dBAAt Duty Cycle 50%: 35.1 dBAAt Duty Cycle 100%: 51.4 dBA
Air Pressure -
Lead Wire Pin Out Pin1-Black (-)Pin2-Yellow (+)Pin3-Green (Techometer/Signal output)Pin4-Blue (PWM)
Note 1. Thermal Grease Pre-Printed with GE-Toshiba TIG830SP2. RoHS Compliance3. Backplate is not included.
