ELP High Speed Wide Angle Global Shutter USB Module for Computer 1080P 2mp
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
ELP High Speed Wide Angle Global Shutter USB Module for Computer 1080P 2mp
Price: US $50.00
google manual for full detailed, I used it for 4 months taking vidoes of slot car racings.Model: ELP-USBGS1200P01-SH120
  • Sensor: Aptina AR0234 (1/2.6”) Global Shutter
  • Max Resolution: 1920 (H) *1200 (V)
  • Lens Size: 1/2.6 inch (4:3)
  • Pixel Size: 3.0μm
  • Compression Format: MJPEG / YUV2 (YUYV)
  • Resolution & Frame rate:
  • 1920x1200@90fps MJPEG/1920x1080@90fps MJPEG 1600x1200@90fps MJPEG/1280x960@90fps MJPEG
  • 1280x720@90fps MJPEG/1024x768@90fps MJPEG 960x720@90fps MJPEG/800x600@90fps MJPEG 640x480@90fps MJPEG/320x240@90fps
  • Sensitivity: 1.4V/lux-sec@550nm
  • Mini Illumination: 0.3lux
  • Shutter: Global Shutter
  • Adjustable Parameters: Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Compensation, Exposure
  • Lens Parameters: HD 120degree no distortion lens
  • USB Cable : 3M
  • Operating System Request: WinXP/Vista/Win7/Win8/Win9/Win10/Win11 etc, Linux with UVC (above linux-2.6.26), MAC-OS X 10.4.8 or later, Android 4.0 or above with UVC
