Use :
Mounts on the M.2 port of laptop PCs (M or B+M), PCIe type (not suitable for M2 SATA type ports)
Compatibility:
Windows ME, 98SE, 2000, XP, Vista, 7, 8,8.1,10,11 - Server 2003, 2008, 2012 / Linux 2.6.x and recent / Mac OS 10.4 and recent
M2 card in 2280 format, suitable for slots 2280 and 22110.
Features :
from al REALTEK RTL8125 Chipset.
2.5G and 1G lite compatible. Auto-negotiation with XNP capability.
Compatible with NBASE-TTM Alliance PHY Specification.
Swap/polarity/skew fixes.
Crossover detection, with automatic correction.
Hard'are supports ECC (Error Correction Code) and CRC (Cyclic Redundancy Check).
Transmit/Receive on-chip buffer.
PCI MSI (Message Signaled Interrupt) and MSI-X compatible.
ECMA-393 ProxZzzy Standard / LTR (Latency Tolerance Reporting) / Microsoft WPI (Wake Packet Indication) compliant.
Compatible with packet wake-up.
Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab.
Supports IEEE 1588v1, IEEE 1588v2, IEEE 802.1AS time synchronization / IEEE 802.1Qav credit-based shaper algorithm / IEEE 802.1P Layer 2 Priority Encoding / IEEE 802.1Q VLAN tagging / IEEE 802.1ad Double VLAN / IEEE 802.3az (Energy Efficient Ethernet) / IEEE functions 802.3bz (2.5GBase-T) / Full Duplex flow control (IEEE 802.3x).
Jumbo frame up to 16K byte..
