Mini Industrial Gigabit PoE Injector 12-48V Input, Passive or IEEE802.3 output
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
Mini Industrial Gigabit PoE Injector 12-48V Input, Passive or IEEE802.3 output
Price: CN $115.11

Ordering information

Please select the product you need based on the parameter table in the picture


802.3af at 30W

►12~48VDC Power Input
►1 RJ45 Ethernet Data Input Port + 1 RJ45 Power Over Ethernet Output Port (Data + Power)
►Support IEEE802.3at Power over Ethernet (PoE+) Power Sourcing Equipment
►Support 10/100/1000Base-TX
►Support DIN-Rail & Wall-mount installation.
►Extensive LED indicators for PoE diagnostics
►Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature


Passive 24V

►12~24VDC Power Input
►1 RJ45 Ethernet Data Input Port + 1 RJ45 Power Over Ethernet Output Port (Data + Power)
►Support Passive 24V Power over Ethernet (PoE) Power Sourcing Equipment
►Support 10/100/1000Base-TX
►Support DIN-Rail & Wall-mount installation.
►Extensive LED indicators for PoE diagnostics
►Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature


802.3af at bt 95W

►1 RJ45 Ethernet Data Input Port + 1 RJ45 Power over Ethernet Output Port (Data + Power)
►Support 95W LTPoE++ Power Sourcing Equipment
►Complies with IEEE 802.3at/bt PoE end-span/mid-span PSE
►Support 10/100/1000Base-TX
►Extensive LED indicators for PoE diagnostics
►12~48V DC wide range power input with power booster function
►Up to 95-watt PoE budget (48VDC), 95-watt PoE budget (24VDC), 60-watt PoE budget (12VDC)
►Supports DIN-Rail and Wall-mount installation
Environmentally Hardened -40°C to 80°C


802.3af at 60W

►12~48VDC Power Input
►2 RJ45 Ethernet Data Input Port + 2 RJ45 Power Over Ethernet Output Port (Data + Power)
►Support IEEE802.3at Power over Ethernet (PoE+) Power Sourcing Equipment
►Max 60W PoE at one port, total POE power less than 60W
►Support 10/100/1000Base-TX
►Support DIN-Rail & Wall-mount installation.
►Extensive LED indicators for PoE diagnostics
►Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature


M12 802.3af at 30W

►12~48VDC Power Input
►Fully compliant with IEEE802.3af/at
►Support 10/100/1000Base-TX for power and data output
►Support DIN-Rail & Wall-mount installation
►Use M12 connectors to ensure tight and robust connections
►Extensive LED indicators for PoE diagnostics
►Environmentally Hardened -40°C to 80°C (-40°F to 176°F) operating temperature
