Omada ES206XPP-M2 Ethernet Switch Brand: TP LINK UPC: 0840460600453 Mfr Part #: ES206XPPM2

General Information

Omada 5-Port 2.5G+1-Port 10G Easy Managed Switch with 4-Port PoE++

ES206XPP-M2

5? 2.5G RJ45 Ports

1? SFP+ Slot

120W Total PoE Budget

Fanless Design for Silent Operation

Easy Centralized Management

Omada App

Traffic Separation

Traffic Prioritization

Power over Ethernet, Flexible Network Deployment

Transmit both data and power via a single cable to other PoE++ devices, without the hassle and cost of installing power cabling. Automatically detect and supply the required power to PoE-enabled devices.

4? 2.5GPoE++RJ45 Ports

Up to90Wper Port

Total120WPoE Budget

Compatible with802.3af/at/btPoE and non-PoE devices

Access Point

Gaming Consoles

4k Video 8K/4K Video

Computer

Unlock the Highest Performance of 2.5G Multi-Gig Bandwidth and Devices

2.5G WiFi7/6 APs

2.5G Gaming Computer

2.5G NAS/Server

PoE Lighting

Works with Omada Central Essentials for Free and Easy Cloud Management

Omada Central Essentials provides free and easy-to-use centralized cloud management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.

Cost-Performance Solution | Looking for free, worry-free cloud management for life?

Omada Central Essentials

Lifetime Free Cloud without Additional Fees

On-site work eating up time and resources?

Reduce Maintenance Costs

Manage and Maintain from Anywhere

Multiple Application Scenarios | Wi-Fi Coverage

Works with Wi-Fi 6/7 Access Points

LAN Party

Works with Gaming Consoles and TVs

Wired Connections

Works with Non-PoE Devices such as PCs and Printers

Technical InformationFeatures:Plug and PlayFeatures:Remote/Cloud ManagementFeatures:Virtual LAN (VLAN)Features:Quality of Service (QoS)Features:IGMP Provisioning (ZTP)Features:Link AggregationFeatures:Flow ControlFeatures:Loopback DetectionFeatures:Port MirroringFeatures:Cable Storm ControlFeatures:Multicast Storm ControlFeatures:Unicast Storm ControlFeatures:Loop Protection

Media & PerformanceMedia Type Supported:Optical FiberMedia Type Supported:Twisted PairEthernet Technology:10 Gigabit EthernetEthernet Technology:2.5 Gigabit EthernetNetwork Technology:2.5GBase-TNetwork Technology:10GBase-XMaximum Data Transfer Rate:1.25 GB/s

I/O ExpansionsTotal Number of Expansion Slots:1Expansion Slot Type:SFP+Number of SFP+ Slots:1

Network & CommunicationLayer Supported:2Networking Standards:IEEE 802.1abNetworking Standards:IEEE 802.3xNetworking Standards:IEEE 802.3btNetworking Standards:IEEE 802.3atNetworking Standards:IEEE 802.3af

Management & ProtocolsManageable:YesSwitch Management Type:Easy Managed

Power DescriptionPoE (RJ-45) Port:YesPoE Budget:120 WInput Voltage:120 V ACInput Voltage:230 V ACFrequency:50 HzFrequency:60 HzPower Source:ACPower Source:Power Adapter

Physical CharacteristicsProduct Material:MetalForm Factor:DesktopForm Factor:Wall (Approximate):1.48 lb

ES206XPP-M2 Ethernet Switch

Power Adapter

Power Cord

Mounting Feet

Installation Access Surveillance NetworkApplication/Usage:Gaming ComputerCertifications & Compliance:Restriction of Hazardous Substances (RoHS)
