￭ Standard SFX form factor
￭ Silent running 92mm dual ball bearing fan with minimum 0dBA
￭ All Japanese capacitors
￭ High efficiency with 80 PLUS Platinum certification
￭ Class-leading single +12V rail
￭ Strict ±3% voltage regulation and low ripple & noise
￭ 100% modular cables
￭ All cables with flexible flat arraysModel (on safety) SST-SX750-PTColor Black（Lead-Free Paint）Combined +3.3V & +5V 120WCombined +12V 750WInput Voltage 90V ~ 264VInput Frequency Range 47Hz ~ 63HzPFC Active PFC（PF>0.9 at full load）Efficiency 89% ~ 92% at 20% ~ 100% loadingMTBF 100,000 hoursOperating temperature 0°C ~ 40°CProtection Over Power ProtectionOver Voltage ProtectionShort Circuit ProtectionOver Temperature ProtectionOver Current ProtectionConnectors 1 x 24 / 20-Pin motherboard connector（300mm）1 x 8 / 4-Pin EPS / ATX 12V connector（400mm）2 x 8 / 4-Pin EPS / ATX 12V connector（400mm / 150mm）4 x 8 / 6-Pin PCIE connector（”400mm / 150mm” x 2）8 x SATA connector（”300mm / 200mm / 100mm / 100mm” x 2）3 x 4-Pin Peripheral connector（300mm / 200mm / 200mm）Cooling System Single 92mm dual ball bearing fanForm factor SFXNoise Level 0 dBA minimumDimension 125 mm (W) x 63.5 mm (H) x 100 mm (D)4.92" (W) x 2.5" (H) x 3.94" (D)Weight 1.01 KgCertification
