Product SKUs
Physical Stats
Form Factor
·Mini-ITX
Dimension
·6.7" x 6.7" (17.02cm x 17.02cm)
Processor
CPU
·Intel® Xeon® W-1200 Processors, 11th/10th Generation Intel® Core™ i9/Core™ i7/Core™ i5/Core™ i3 Processor
·Single Socket Socket H5 (LGA-1200) supported, CPU TDP supports Up to 65W TDP
Core
·Up to 10 cores
Note
·** Motherboard supports this maximum TDP. Please verify your system can thermally support.
**The X12SCV-LVDS does not support the Intel 10th/11th generation processor 2M cache SKUs. These processors will not boot with the latest BIOS version.
System Memory
Memory Capacity
·2 DIMM slots
·Up to 64GB ECC/non-ECC SODIMM, DDR4-2933MT/s
Memory Type
·2933/2666/2400/2133 MT/s ECC/non-ECC DDR4 SODIMM
DIMM Sizes
·4GB, 8GB, 16GB, 32GB
Memory Voltage
·1.2V
Error Detection
·Corrects single-bit errors
·Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset
·Intel® W480E
SATA
·Intel® W480E controller for 2 SATA3 (6 Gbps) ports; RAID 0,1
Audio
·ALC 888S HD Audio
Graphics
·1 Intel® HD Graphics port(s)
·3 Independent Displays thru HDMI 2.0a/HDMI1.4/DP/LVDS
Network Controllers
·Single LAN with Intel® PHY I219LM LAN controller
·Single LAN with Intel® Ethernet Controller I210-AT
Input / Output
SATA
·2 SATA3 (6Gbps) port(s)
LAN
·2 RJ45 Gigabit Ethernet LAN ports
USB
·4 USB 2.0 port(s) (4 via header)
·4 USB 3.2 Gen2 port(s) (4 rear type A)
Video Output
·1 DP (DisplayPort) port(s), 2 HDMI port(s), 1 LVDS port(s)
Serial Port
·2 COM ports via 1 header
DOM
·1 SuperDOM(Disk on Module) ports
TPM
·1 TPM Header & Chip both
Expansion Slots
PCIe
·1 PCIe 3.0 x16 slots (16/NA or 8/8)
M.2
·M.2 Interface: 1 CNVi/PCIe 3.0 x1; 1 SATA/PCIe 3.0 x4
·Form Factor: 2230, 2242/2280
·Key: E-Key, M-Key
System BIOS
BIOS Type
·AMI UEFI
BIOS Features
·ACPI 6.1
·SMBIOS 3.1
·PCI FW 3.0
·UEFI 2.7
·RTC (Real Time Clock) Wakeup
Management
System Management Software
·SuperDoctor 5
Power Configurations
·ATX Power connector, ACPI / ACPM Power Management, +12V DC Power Input
Security
Hardware
·Trusted Platform Module (TPM) 2.0
PC Health Monitoring
Voltage
·VBAT, System temperature, System level control, PCH temperature, Monitors CPU voltages, HT, CPU temperature, Chipset Voltage, 3 -fan status, +3.3V, +1.8V
LED
·Power LED
Temperature
·Thermal Control for 3 Fan Connectors
FAN
·3x 4-pin fan headers (up to 3 fans)
·System level control
·PWM fan speed control
·Fan speed control
·3 fans with tachometer monitoring
Other Features
·WOL, System level control, RoHS, M.2 NGFF connector, Chassis intrusion header, ATX Power connector, ACPI power management, 8-pin 12v DC power connector, 12V DC or ATX Power Source
Operating Environment
Operating Temperature Range
·0°C - 60°C (32°F - 140°F)
Non-Operating Temperature Range
·-40°C - 85°C (-40°F - 185°F)
Operating Relative Humidity Range
·10% - 85% (non-condensing)
Non Operating Relative Humidity Range
·10% - 95% (non-condensing)
