Features & Benefits
• Supports multiple operating systems including Linux, MAC OS, and Windows.
• USB bus-powered, eliminating the need for external power sources.
• Allows customization for hardware, firmware, and software development.
• Max transmission rate of up to IM bps with a compact size of 66.5mm x20.5mmx8.5mm.
• Compatible with up to 100 USB-CAN adapters on a single PC.
• Ideal for both data acquisition and analysis in diverse applications.
Multi-Platform Support
Compatible with Windows, Linux, Mac, Android, and Raspberry Pi, ensuring versatility for diverse developer environments and projects.
Enhanced Connectivity
Equipped with SPI, ADC, DAC, and GPIO, enabling seamless integration with various devices and efficient communication across different applications.
Compact Design
The mini USB form factor makes it portable and easy to incorporate into projects, perfect for on-the-go developers and engineers.
CAN bus data sending and receiving via USB of PC or Smart Device USB
U CAN bus to USB gateway
U CAN network data acquisition and analysis
USB to CAN network interface.
Extend the distance of CAN bus × 3.43 × 1.34 inches (11.7 × 8.7 x
3.4 cm)
Item Weight
0.317 ounces (8.99 grams)
Performance:
- USB 2.0;bus-powered
- Portable size
- Max transmission rate up to 1M bps;Min transmission rate 2K bps
- 4 Channels of ADC (12bit)
- 2 Channels of DAC
- 5 channels GPIO outgoing control
- 1 channels Pulse counter input
- 2 channels PWM signal output; frequency range: 1Hz to 20MHz
- Above peripheral may be or may not be used simultaneously as pinout limitation
- Safe voltage: 0~5V
- Item size: 66.5mmx20.5mmx8.5mm,weight: 9g
- Temperature range: -40°C~85°C
