WAVLINK Outdoor WiFi Series | Product Comparison & Buying GuideWAVLINK Outdoor WiFi Series
Product Comparison & Buying Guide
WiFi 6 & WiFi 5 outdoor access points engineered for long-range coverage, harsh weather and flexible PoE deployment — from a backyard patio to a 3km point-to-point link.
WiFi 6 AX3000 / AX1800 Up to 3 km PtP / PtMP IP67 Weatherproof Active & Passive PoE Mesh / AP / Router / Repeater Product Comparison
Find the right model at a glance. Table 1 covers the WiFi 6 lineup, Table 2 covers the WiFi 5 / N series.
Table 1 · WiFi 6 Series AX3000 / AX1800
ModelStandardMax SpeedAntennasOutdoor 6 AX30005GHz 2402Mbps + 2.4GHz 573Mbps4 × 12dBi DirectionalUp to 1.5km (Paired PtP/PtMP)IP67Active 802.3af/at + Passive3km long-distance wireless data transmissionWL-WN573HX3WiFi 6 AX30005GHz 2402Mbps + 2.4GHz 573Mbps4 × 8dBi Omnidirectional (Fiberglass Tube)Up to 300mIP67 · 15kV ESD · 6kV LightningActive 802.3af/at + PassiveFiberglass antennas + PA/LNA amplifiersWL-WN588HX3WiFi 6 AX30005GHz 2402Mbps + 2.4GHz 573Mbps6 × 7dBi OmnidirectionalUp to 300mIP67802.3af / 802.3at / 48V PoEConnect up to 256 devices simultaneouslyWL-WN573HX1WiFi 6 AX18005GHz 1201Mbps + 2.4GHz 574Mbps4 × 8dBi OmnidirectionalUp to 250mIP67 · 15kV ESD · 6kV LightningActive 802.3af/at + PassiveBest value entry into WiFi 6 outdoors
Table 2 · WiFi 5 / N Series AC1200 · AC600 · N300
ModelStandardMax SpeedAntennasOutdoor RangeProtectionPoEHighlightWL-WN588HA2
(2026 Version)WiFi 5 AC12005GHz 867Mbps + 2.4GHz 300Mbps4 × 7dBi Omni (RP-SMA, Detachable)Up to 200mIP67 · 15kV ESD · 6kV LightningActive 802.3AT/AR + PassiveGigabit port · MU-MIMO · Beamforming · AC controller readyWL-WN570HA2WiFi 5 AC12005GHz 867Mbps + 2.4GHz 300Mbps2 × 7dBi OmnidirectionalUp to 150mIP67 · 15kV ESD · 6kV LightningActive 48V + Passive 54VSupports up to 32 devices · 4 working modesWL-WN572HP3 HOTWiFi 5 AC12005GHz 867Mbps + 2.4GHz 300Mbps4 × 7dBi OmnidirectionalUp to 200mIP65 · 15kV ESD · 4kV LightningPassive PoE (24V)Dual Gigabit ports · 64–96 devices · 800mW PAWL-WN570HN2-BN300 Single-Band2.4GHz 300Mbps2 × 7dBi OmnidirectionalUp to 50mIP67 · 15kV ESD · 6kV LightningActive 48V + Passive 54VCost-effective basic outdoor coverageWL-WN570HA1WiFi 5 AC6005GHz 433Mbps + 2.4GHz 150Mbps2 × 7dBi Dual-Polarized OmniUp to 100mIP65Passive PoE1000mW high power · WISP / CPE / Video surveillanceWhich One Fits Your Scenario?
Pick the model that matches your distance, device count and installation environment.
🛰️Cross-Building / Long-Distance Backhaul
Connecting two buildings, a warehouse to an office, or a remote gate to the main network — a stable point-to-point link over a long span.
➜ WL-WN573HP3 (3km PtP/PtMP) 🏡Large Yard, Garden & Farm
Need wide outdoor WiFi 6 coverage with strong anti-interference and a rugged build that survives rain, snow and wind.
➜ WL-WN573HX3 / WL-WN588HX3 🏭Factory, Street, Community, Campus
High-density areas where many phones, cameras and sensors connect at the same time and full-area roaming matters.
➜ WL-WN588HX3 (up to 256 devices) 💰First Step into Outdoor WiFi 6
Want WiFi 6 speed and IP67 protection at a friendly budget for a patio, poolside or small courtyard.
➜ WL-WN573HX1 (AX1800) ⚡Gigabit Wired Backbone Outdoors
You already have a gigabit router or switch and want to push full wired speed into an outdoor wireless zone.
➜ WL-WN588HA2 (2026, Gigabit Port) 🏊Poolside, Parking Lot, Courtyard
Extend an existing home or office WiFi outdoors with a simple, reliable and weatherproof access point.
➜ WL-WN570HA2 / WL-WN572HP3 🔧Business-Grade Outdoor Coverage
Factories, workshops and commercial sites that need dual Gigabit ports, high power output and many concurrent devices.
➜ WL-WN572HP3 (800mW PA, 64–96 devices) 📹Wireless ISP, CPE & Video Surveillance
Long-range signal pick-up and stable transmission for cameras, remote monitoring or WISP access.
➜ WL-WN570HA1 (1000mW, WISP/CPE) 🌱Basic 2.4GHz Outdoor Extension
A budget-friendly way to push 2.4GHz coverage into a shed, garage or small outdoor area.
➜ WL-WN570HN2-B (N300) Product Details
Full feature and specification breakdown for every model in the lineup.
WiFi 6 · AX3000 3KM LONG RANGE AX3000 WiFi 6 Outdoor Access Point — 1.5km (PtP / PtMP)
Model: WL-WN573HP3
Built for long-distance wireless data transmission over 3km, with 4 × 12dBi directional antennas that dramatically improve signal transmission and reception.
🌐 Designed for Harsh Outdoor Conditions
IP67-rated waterproof housing keeps the unit running in extreme cold, heat or continuous moisture. Lightning protection and weatherproof design ensure a stable connection outdoors.
🌐 Enjoy True WiFi 6 Speed
Next-generation WiFi compliant with IEEE 802.11 ax/ac/a/b/g/n. Dual-band speeds up to 5GHz 2402Mbps and 2.4GHz 573Mbps — enjoy HD video and smooth gaming even outdoors.
🌐 Optional PoE Power Supply
Supports 802.3AF/AT active PoE and passive PoE, delivering data and power over a single Ethernet cable — ideal where no power outlet is available.
🌐 Seamless WiFi Roaming
4 × 12dBi directional antennas plus high-power amplifiers deliver extreme coverage and penetration. Everything Mesh technology expands coverage with one click and eliminates dead zones.
🌐 Multiple Modes, Flexible Use
Mesh, AP, Router, Repeater and AP+Repeater modes cover every outdoor scenario. Router/AP mode converts wired into wireless; Mesh mode gives one network name and password.
🌐 1.5km Wireless Data Transmission
Specially designed for outdoor use and tested in barrier-free fields — ideal for long-distance wireless data transmission over 3km / 1.9 miles when paired PtP or PtMP.
In the Box
1× AX3000 WiFi 6 Outdoor Access Point · 1× 54V Power Adapter · 4× Cable Ties · 1× PoE Converter · 2× Silicone Pads · 1× Ethernet Cable · 1× Main Body Holder · 1× PWM M4×8×8MM Screw · 1× Wrench · 6× KA M4×25×6MM Screws · 6× Φ8×25MM Screw Plugs · 1× Quick Start Guide
WiFi 6 · AX3000 UP TO 300M AX3000 WiFi 6 Outdoor Access Point — Up to 300m
Model: WL-WN573HX3
Fiberglass-tube high-gain antennas combine wind resistance, corrosion resistance and boosted WiFi coverage — a perfect fit for exposed outdoor installation.
⭐ Designed for Harsh Outdoor Conditions
IP67 waterproof enclosure, 15kV ESD protection and 6kV lightning protection keep it working in rain, snow, wind and thunder. Fiberglass tube antennas withstand strong wind and corrosion while boosting coverage.
⭐ Enjoy True WiFi 6 Speed
Dual-band speeds up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference and congestion for lightning-fast internet, HD video and smooth gaming outdoors.
⭐ Optional PoE Power Supply
802.3AF/AT active PoE and passive PoE supported — data and power over one Ethernet cable, so you can install outdoors where no outlet exists.
⭐ Seamless WiFi Roaming
4 × 8dBi omnidirectional antennas and two built-in high-power amplifiers deliver extreme coverage and penetration. Mesh technology expands coverage and removes every dead zone with one click.
⭐ Multiple Modes, Flexible Use
Mesh, AP, Router, Repeater and AP+Repeater modes cover more outdoor scenarios. Mesh mode gives seamless WiFi with a single network name and password.
⭐ High Power Amplifiers
Dual integrated signal boosters strengthen wireless performance: the PA increases power output while the LNA minimizes noise and amplifies the wireless signal.
In the Box
1× AX3000 WiFi 6 Outdoor Access Point · 4× Omni Antennas · 4× Cable Ties · 1× Ethernet Cable Connector · 1× Quick Installation · 1× Wrench · 2× Silicone Pads · Several Screws · Passive PoE: 1× 54V Power Adapter, 1× PoE Converter, 1× Ethernet Cable
WiFi 6 · AX3000 WIDER COVERAGE AX3000 WiFi 6 Outdoor Access Point — Wider Coverage
Model: WL-WN588HX3
6 × 7dBi omni-directional antennas and built-in high-power amplifiers extend outdoor signal coverage up to 300m (984ft) — with capacity for up to 256 devices.
🌐 Designed for Harsh Outdoor Conditions
IP67-rated waterproof housing ensures continued operation in harsh outdoor environments or climates of extreme cold, heat or continuous moisture, with lightning protection for a stable connection.
🌐 Enjoy True WiFi 6 Speed
Dual-band speeds up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference and congestion. Enjoy HD videos and smooth gaming even outdoors.
🌐 Seamless WiFi Roaming
6 × 7dBi omni-directional antennas plus high-power amplifiers deliver extreme coverage and penetration. Everything Mesh technology expands coverage with one click.
🌐 Multiple Modes, Flexible Use
Mesh, AP, Router, Repeater and AP+Repeater modes meet different needs across outdoor scenarios, with seamless roaming under a single network name and password.
🌐 Powered by PoE & Flexible Installation
802.3af / 802.3at / 48V PoE with the included PoE adapter. The mounting bracket design allows easy installation on poles or walls.
🌐 Access More Devices
Connect up to 256 devices simultaneously — ideal for large spaces such as factories, communities, streets and more.
In the Box
1× AX3000 WiFi 6 Outdoor Access Point · 4× Plastic Cable Ties · 1× Main Body Holder · 6× 7dBi Antennas · 1× Wrench · 1× 54V Power Adapter · 1× PoE Converter · 1× Ethernet Cable · 1× PWM M3×5×6MM Screw · 6× KA M3×20×5.2MM Screws · 6× Φ6.5×25MM Screw Plugs · 1× Quick Start Guide
WiFi 5 · AC1200 2026 VERSION AC1200 WiFi 5 Outdoor Access Point — Approx. 200m (2026 Version)
Model: WL-WN588HA2 (AERIAL HD8S)
Upgraded Wi-Fi 5 platform with MU-MIMO and Beamforming, a Gigabit WAN/LAN port and 4 × 7dBi detachable omni antennas for stable, wider outdoor coverage.
Upgrade to Wi-Fi 5
Dual Band AC1200 delivers 2.4GHz@300Mbps and 5GHz@867Mbps, compliant with IEEE 802.11ac/a/n/g/b. MU-MIMO and Beamforming reduce interference for stable, wider coverage and more connected devices.
Expand Coverage Area
4 × 7dBi omni detachable antennas with up to 1000MW power and a built-in high-power PA+LNA amplifier. Receives existing 2.4GHz and 5GHz signals and extends the range of your router or access point up to 300 meters.
Professional Outdoor Design
Indoor/outdoor use with wall or pole mount, robust IP67 weatherproof casing and grounding terminal, 15KV ESD protection and 6KV lightning protection. Withstands −20°C to 50°C for stable operation in various weather.
Flexible Mode Selection
AP / Repeater / Router mode connects to most wireless signals, including Starlink. Mesh mode allows seamless home roaming with a single SSID and password, paired easily with one touch — and compatible with the Wavlink AC controller for unified management in large networks.
Powered by PoE
Supports 802.3AT/AR Active PoE and Passive PoE, integrating power and network data over a single cable — simplifying outdoor setup and enabling installation where no power source exists.
Mesh Networking Ready
Supports mesh networking with up to 8 devices (including the main router) when paired with Wavlink Everything Mesh products of the same brand.
In the Box
1× ACI200 Wi-Fi 5 Outdoor Access Point · 4× Plastic Cable Ties · 1× Main Body Holder · 4× 7dBi Antennas · 1× Wrench · 1× 54V Power Adapter · 1× PoE Converter · 1× Ethernet Cable · 1× PWM M3×5×6MM Screw · 6× KA M3×20×5.2MM Screws · 6× Φ6.5×25MM Screw Plugs · 1× Quick Start Guide
WiFi 5 · AC1200 APPROX. 150M AC1200 Dual Band Outdoor Access Point — Approx. 200m
Model: WL-WN570HA2
A dependable Wi-Fi 5 outdoor AP with active/passive PoE, IP67 weatherproofing and a maximum coverage range of 200 meters — ideal for yards, pools and parking lots.
AC1200 Dual-Band Range Extender
With Wi-Fi 5 technology at its core, speeds reach up to 1200Mbps — ideal for smooth HD streaming, online gaming and bandwidth-heavy activities. Enjoy dependable connectivity in the yard, by the pool or in a parking lot.
Power Over Ethernet
Integrated PoE consolidates power and network data into a single RJ-45 cable, allowing installation in areas without power outlets. Equipped with passive PoE and also supporting active PoE — you can connect your own active switch.
IP67 Rated Weatherproof Case
The IP67-rated weatherproof and heat-resistant enclosure ensures continued operation in harsh outdoor environments, including extremely cold, hot or constantly humid climates. Withstands −10°C to 50°C, plus 15KV ESD and 6KV lightning protection.
Multiple Working Modes
Four working modes: Repeater mode extends existing Wi-Fi coverage; Router mode creates an instant private wireless network; AP mode converts wired to wireless; AP+Repeater mode amplifies and relays the signal from an access point.
Outdoor Access Point
Delivers 300Mbps over 2.4G and 867Mbps over 5G, with a maximum coverage range of 200 meters and support for up to 32 devices. Simple settings enable wireless optimization for better link quality and effectiveness.
Easy Outdoor Installation
Wall or pole mounting with a compact body (18 × 5 × 5cm) and two 7dBi omni-directional antennas. Best installed 2–3 meters above ground for optimal performance.
In the Box
1× AC1200 Dual Band Access Point · 2× 7dBi High-gain Antennas · 1× RJ-45 Ethernet Cable · 1× Power Adapter · 1× PoE Converter · 1× Main Body Holder · 2× Cable Ties · 1× Screw Fitting Kit · 1× Quick Start Guide
WiFi 5 · AC1200 HOT SALE AC1200 High Power Outdoor Weatherproof WiFi Range Extender / Access Point — Approx. 200m
Model: WL-WN572HP3
Dual Gigabit Ethernet ports, 800mW high-power amplifiers and 4 × 7dBi detachable omni antennas — built for factories, communities, streets and large outdoor areas.
AC1200 Dual-Band & Upgraded Chip & Easy Mesh
Complies with IEEE 802.11 ac/a/b/g/n with dual-band speeds up to 5GHz 867Mbps and 2.4GHz 300Mbps. A brand-new MT7621A chip and Easy Mesh support keep 64~96 devices connected simultaneously, and let Wavlink mesh routers/APs/repeaters work together.
Multiple Modes & PoE & Dual Gigabit Ports
Supports Mesh Extender Mode, Access Point (AP) Mode and Repeater Mode. Integrated PoE combines power and network data into a single RJ-45 cable. Dual Gigabit LAN/WAN ports support 10/100/1000Mbps — 10× faster than a standard Ethernet port.
Designed for Harsh Outdoor Environments
IP65-rated weatherproof and heat-resistant case withstanding −30°C~70°C, plus 15KV ESD and 4KV lightning protection. Key parts are coated with waterproof glue to strictly avoid leakage.
4 × 7dBi Detachable Omni Antennas
Higher antenna gain extensively strengthens the Wi-Fi signal and expands wider coverage in open air. Stability technology automatically avoids channel conflicts using its channel selection feature — covering hard-to-reach dead zones.
High Power Amplifiers
PA 800mW and an enhanced receiver design deliver stronger penetration and longer range than general access points — ideal for providing Wi-Fi service in big areas such as factories, communities and streets.
Worry-Free Support
12-month worry-free warranty (extra 6 months for registered members) and life-long technical support.
In the Box
1× AC1200 Dual Band Outdoor AP/Range Extender · 2× 2.4G Omni Antennas · 2× 5G Omni Antennas · 1× RJ-45 Networking Cable · 1× Power Adapter · 1× PoE Converter · 1× Main Body Holder · 2× Cable Ties · 1× Screw Fitting Kit · 1× Quick Start Guide
WiFi 6 · AX1800 WIDE COVERAGE AX1800 WiFi 6 Outdoor Access Point — Wide Coverage
Model: WL-WN573HX1
WiFi 6 efficiency and IP67 protection at an accessible price — 4 × 8dBi omni antennas with dual built-in high-power amplifiers for wide outdoor coverage.
⭐ Designed for Harsh Outdoor Conditions
IP67 waterproof enclosure, 15kV ESD protection and 6kV lightning protection keep it operating in rain, snow, wind and thunder. Fiberglass tube high-gain antennas withstand strong wind and corrosion while boosting coverage.
⭐ Enjoy True WiFi 6 Speed
Complies with IEEE 802.11 ax/ac/a/b/g/n with dual-band speeds up to 5GHz 867Mbps and 2.4GHz 300Mbps, avoiding wireless interference and congestion for fast, smooth internet outdoors.
⭐ Optional PoE Power Supply
802.3AF/AT active PoE and passive PoE supported — data and power over a single Ethernet cable, so installation is possible where no power outlet is available.
⭐ Seamless WiFi Roaming
4 × 8dBi omnidirectional antennas and two built-in high-power amplifiers deliver extreme coverage and penetration. Mesh technology expands coverage and eliminates dead zones with one click.
⭐ Multiple Modes, Flexible Use
Mesh, AP, Router, Repeater and AP+Repeater modes cover more outdoor scenarios. Router/AP mode converts wired to wireless; Mesh mode offers seamless WiFi with a single network name and password.
⭐ Ready for Mesh Expansion
Under mesh mode, WN573HX1 supports interconnection with WN531AX2, WN583AX1 and WN573HX1 for easy network expansion.
In the Box
1× Wi-Fi 6 Outdoor Mesh Router/AP/Repeater · 4× Omni Antennas · 4× Cable Ties · 1× Ethernet Cable Connector · 1× Quick Installation · 1× Wrench · 2× Silicone Pads · Several Screws · Passive PoE: 1× 54V Power Adapter, 1× PoE Converter, 1× Ethernet Cable
N300 · 2.4GHz APPROX. 100M N300 Wireless Outdoor Access Point with PoE Powered
Model: WL-WN570HN2-B
A straightforward, weatherproof 2.4GHz outdoor access point with PoE power, WAN/LAN port and four flexible working modes.
Power Over Ethernet
Integrated PoE consolidates power and network data into a single RJ-45 cable, allowing installation in areas without power outlets. Equipped with passive PoE and also supporting active PoE — connect your own active switch.
IP67 Rated Weatherproof Case
The IP67-rated weatherproof and heat-resistant enclosure ensures continued operation in harsh outdoor environments including extremely cold, hot or constantly humid climates, withstanding −10°C to 50°C. Includes 15KV ESD and 6KV lightning protection.
Multiple Working Modes
Four working modes: Repeater mode extends existing Wi-Fi coverage; Router mode creates an instant private wireless network; AP mode converts wired to wireless; AP+Repeater mode amplifies and relays the signal from an access point.
Outdoor Access Point
Maximum coverage range of 150 meters, support for up to 32 devices, and 2.4GHz 300Mbps high-speed performance with a 100M Ethernet port. Simple settings enable wireless optimization to improve link quality.
Single-Band Range Extender
Powered by 802.11n Wi-Fi technology, it enhances your existing wireless coverage on the 2.4GHz band at speeds up to 300Mbps — great for high-speed downloads of games, videos and files even in public areas.
Easy Outdoor Mounting
Compact 18 × 5 × 5cm body with two 7dBi omni-directional antennas. Install 2–3 meters above the ground for the best performance.
In the Box
1× N300 Outdoor Access Point · 2× 7dBi High-gain Antennas · 1× RJ-45 Ethernet Cable · 1× Power Adapter · 1× PoE Converter · 1× Main Body Holder · 2× Cable Ties · 1× Screw Fitting Kit · 1× Quick Start Guide
WiFi 5 · AC600 APPROX. 100M AC600 7dBi High Power Outdoor Omni-directional Access Point / CPE / Repeater / WISP
Model: WL-WN570HA1
1000mW of transmit power and dual-polarized 7dBi antennas deliver a compelling long-range solution for video surveillance, WISP and CPE deployments.
Wavlink Brings Technology to Life
WN570HA1 is designed to provide WISP and CPE solutions and long-range wireless network coverage for video surveillance and transmission. With two omni-directional 7dBi dual-polarized antennas and strong transmit power of up to 1000mW, it delivers compelling performance for small and growing businesses at a very affordable price — and provides an efficient way to pick up and maintain a stable signal over long distances.
Withstand Harsh Climates
WN570HA1 has an IP65-rated weatherproof housing that ensures continued operation in harsh outdoor environments or in climates of extreme cold, heat or continuous moisture.
Easy Installation With Power over Ethernet
By combining power and data connection into a single cable, PoE simplifies the setup of the high-power outdoor WiFi Access Point/Bridge. Combining power and network access into a single RJ-45 connection lets you install the WN570HA1 in hard-to-reach locations without running both power and Ethernet cables.
Dual-Band Flexibility
Supports 2.4GHz 150Mbps and 5GHz 433Mbps, compliant with IEEE 802.11 ac/a/b/g/n. Maximum WLAN security with WPA2, WPA and WEP (128/64).
Long-Range Performance
Outdoor coverage up to 100m depending on the actual environment. For the most reliable connection, select a wireless network with signal strength greater than 70%.
Optimal Installation
Install the outdoor antenna at a height of 2 meters above the roof or in a high open place for better reception.
In the Box
1× WiFi AP/Router · 2× Antenna · 1× Power Adapter · 1× PoE Converter · 1× RJ-45 Networking Cable · 1× Main Body Holder · 1× Screw Fitting · 2× Cable Ties · 1× Quick Installation Guide
