Description
RGB full-color LED matrix panel, 2mm Pitch, 64 × 64 pixels, adjustable brightness, options for Standard version / GOB version 64 × 64 full-color LED matrix panel

* the product includes the display only and requires a host controller, such as Raspberry Pi, Pico, ESP32, or Arduino for display output.

RGB-Matrix-P2-64x64-B

RGB-Matrix-P2-64x64
Features at a glance

The product is a 64 × 64 resolution full-color RGB LED dot matrix module, integrating 4096 LEDs and equipped with dual HUB75 headers, supporting cascade expansion and rapid integration. The GOB version features enhanced encapsulation, improving protection and operational reliability.

* only theRGB-Matrix-P2-64x64-Bmodel is a GOB display.

* this back view is for reference only, PCB silkscreen and layout may have small differences from batch to batch, but the software is compatible.
Pin Description Pin Description +5V 5V power input GND Ground R1 R higher bit data R2 R lower bit data G1 G higher bit data G2 G lower bit data B1 B higher bit data B2 B lower bit data A A line selection B B line selection C C line selection D D line selection E E line selection CLK clock input LAT/STB latch pin OE output enable
RGB-Matrix-P2-64x64 It is recommended to used with a5V 4A power supply
