please make sure this item is the correct one your wanted before purshasing.

Motherboard Description:

• Unique On/Off Charge delivers the best recharging capability to iPad, iPhone and iPod Touch
• 3x USB power delivery for greater compatibility and extra power for USB devices
• Leading quality standard of Ultra Durable™ 3 classic technology with 2oz copper PCB design
• Innovative Smart 6 technology for smarter PC management
• Supports Intel Core™ i7/ Core™ i5/ Core™ i3 LGA1156 processors
• Dynamic Energy Saver™ 2 technology enables best energy efficiency
• 2 PCI-E 2.0 x16 graphics interface(x16+x4) with ATI CrossFireX support for ultimate graphics performance
• AutoGreen technology Greening your PC via Bluetooth cellphone
• Patented DualBIOS™ technology delivering highest level failure protection
• Easy BIOS setting for GPU overclocking
• Supports 6 devices without the need for drivers to be installed before being fully operational
• Enhanced Intel HD Graphics integrated with the processor
• Integrated HDMI/ DVI/ DisplayPort interface for smoother HD video playback
• High-performance DAC with 108 dB Signal-to-Noise ratio playback quality
• Compatible with Windows 7 to deliver the best operation experience
• Meet European Union ErP(Energy-related Products) requirement

CPU

1. Support for an Intel® Core™ i7 series processor/Intel® Core™ i5 series processor/ Intel® Core™ i3 series processor in the LGA1156 package
2. L3 cache varies with CPU

(Please refer "CPU Support List" for more information.)

Chipset

1. Intel® H55 Express Chipset

Memory

1. 4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory (Note 1)
2. Dual channel memory architecture
3. Support for DDR3 2200+/1800/1600/1333/1066/800 MHz memory modules
4. Support for non-ECC memory modules
5. Support for Extreme Memory Profile (XMP) memory modules

* To reach DDR3 2200 MHz and above, you are required to use with Intel Core i7/Core i5 CPU without HD Graphics and install a discrete graphics card.
When using Intel Core i5/Core i3/ Pentium CPU with HD Graphics, the maximum memory speed supported is 1666 MHz
* Please refer "Memory Support List" for more information.

Onboard Graphics

Integrated in the Chipset:

1. 1 x D-Sub port (Note 2)
2. 1 x DVI-D port (Note 2) (Note 3) (Note 4)
3. 1 x HDMI port(Note 2) (Note 4)
4. 1 x DisplayPort (Note 2) (Note 4)

Audio

1. Realtek ALC889 codec
2. High Definition Audio
3. 2/4/5.1/7.1-channel
4. Support for S/PDIF In/Out
5. Support for CD In

LAN

1. 1 x RTL8111D chip (10/100/1000 Mbit)

Expansion Slots

1. *1 x PCI Express x16 slot, running at x16 (PCIEX16) (Note 5)
   (The PCIEX16 slot conforms to PCI Express 2.0 standard.)
2. *1 x PCI Express x16 slot, running at x4 (PCIEX4) (Note 6)
3. 2 x PCI slots

Multi-Graphics Technology

1. Support for ATI CrossFireX™ technology(Note 6)

Storage Interface

Chipset:

1. 5 x SATA 3Gb/s connectors supporting up to 5 SATA 3Gb/s devices
2. 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA 3Gb/s device

JMicron JMB368 chip:

1. 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices

iTE IT8720 chip:

1. 1 x floppy disk drive connector supporting up to 1 floppy disk drive

USB

1. Integrated in the Chipset
2. Up to 12 USB 2.0/1.1 ports (6 on the back panel, 6 via the USB brackets con- nected to the internal USB headers)

IEEE 1394

1. T.I. TSB43AB23 chip
2. Up to 2 IEEE 1394a ports (1 on the back panel, 1 via the IEEE 1394a bracket connected to the internal IEEE 1394a header)

Internal I/O Connectors

1. 1 x 24-pin ATX main power connector
2. 1 x 4-pin ATX 12V power connector
3. 1 x floppy disk drive connector
4. 1 x IDE connector
5. 5 x SATA 3Gb/s connectors
6. 1 x CPU fan header
7. 1 x system fan headers
8. 1 x front panel header
9. 1 x front panel audio header
10. 1 x CD In connector
11. 1 x S/PDIF In header
12. 1 x S/PDIF Out header
13. 3 x USB 2.0/1.1 headers
14. 1 x IEEE 1394a header
15. 1 x serial port header
16. 1 x clearing CMOS jumper

Back Panel Connectors

1. 1 x PS/2 keyboard or PS/2 mouse port
2. 1 x D-Sub port (Note 2)
3. 1 x DVI-D port (Note 2) (Note 3) (Note 4)
4. 1 x HDMI port (Note 2) (Note 4)
5. 1 x DisplayPort(Note 2)(Note 4)
6. 1 x IEEE 1394a port
7. 1 x optical S/PDIF Out connector
8. 6 x USB 2.0/1.1 ports
9. 1 x eSATA 3Gb/s connector
10. 1 x RJ-45 port
11. 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/ Side Speaker Out/Line In/Line Out/Microphone)

I/O Controller

1. iTE IT8720 chip

H/W Monitoring

1. System voltage detection
2. CPU/System temperature detection
3. CPU/System/Power fan speed detection
4. CPU overheating warning
5. CPU/System/Power fan fail warning
6. CPU/System fan speed control (Note 7)

BIOS

1. 2 x 64 Mbit flash
2. Use of licensed AWARD BIOS
3. Support for DualBIOS™
4. PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b

Unique Features

1. Support for @BIOS
2. Support for Q-Flash
3. Support for Xpress BIOS Rescue
4. Support for Download Center
5. Support for Xpress Install
6. Support for Xpress Recovery2
7. Support for EasyTune
8. Support for Dynamic Energy Saver™ 2
9. Support for Smart 6™
10. Support for Auto Green
11. Support for Q-Share

Form Factor

1. MicroATX Form Factor; 24.4cm x 23cm

Remark

1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.

Note

(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.
(Note 2) To use the onboard D-Sub, DVI-D, HDMI, and DisplayPort ports, you must install an Intel CPU with integrated graphics.
(Note 3) The DVI-D port does not support D-Sub connection by adapter.
(Note 4) You can use only one of the onboard digital graphics ports (e.g. DisplayPort, HDMI, and DVI-D) for output when in the BIOS Setup program or when during the POST screens.
(Note 5) For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
(Note 6) The PCIEX16 slot operates at up to x4 mode when ATI CrossFireX™ is enabled.
(Note 7) Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install.
(Note 8) Available functions in EasyTune may differ by motherboard model.

Instructions:

• Please DO NOT use fake memory, because the motherboard maybe can't support.

• Please DO NOT use single-side memory, because some motherboards can't support.

• Some CPUs can't be supported by motherboard, please try to update the BIOS, please note that's not motherboard's defect.


• Some "Can't boot" problem's caused by memory, please clean the memory's gold fingers and clean the motherboard's memory solts.


Package Included:

• 1 * motherboard

• 2 * sata cable

• 1 x I/O back panel
