ZA-048 Log-Periodic Antenna

The ZA-048 is a cutting-edge printed Log-Periodic Dipole Array (LPDA) antenna, designed with optimized techniques to significantly reduce its size. This makes it perfectly compatible with various spectrum analyzers and ideal for radio direction finding within the 1 GHz to 8.5 GHz frequency range.

Key Features:

• Wide Frequency Range: Operates within an ultra-wide band of 400 MHz to 8 GHz, offering continuous coverage from low to high frequencies.
• Versatile Applications: Supports wide-range spectrum scanning, spatial interference investigation, and on-site signal direction finding.
• Impedance & VSWR Characteristics: Nominal input impedance of 50Ω with return loss around 10dB or lower in most bands above 1 GHz, ensuring reliable performance.
• Direction-Finding Performance: Excellent sensitivity for locating signal sources, designed for moderate precision applications.
• Stable Tripod Bracket: Features a sturdy tripod support structure with an adjustable clamp compatible with various models, ensuring a professional setup for RF signal direction finding.
• Portable and Compact Design: Lightweight and easy to carry, making it ideal for outdoor mobile testing and on-the-go use.

Package Includes:

• 1x LPDA Antenna (400 MHz-8 GHz)
• 1x Lightweight Tripod Stand
• 1x Adjustable Spectrum Analyzer Clamp

This LPDA antenna is your perfect companion for broadband applications, offering both portability and performance. Experience the ease of use and reliability that this antenna brings to your RF detection and direction-finding needs.
